Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Float 34
-
Groupset X9, X7 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SMOOTHWALL™ Carbon Front Triangle FORM™ Alloy Custom Hydroformed Rear Triangle ABC™ Pivots Tapered Head Tube Press Fit BB Internal Cable Routing Internal \"Stealth\" Dropper Post Routing Internal Shock Remote Routing ISCG05 Tabs RIDE-9™ System Adjustable Geometry & Suspension Rate
Suspension Fork
Fox 34 Float 150 CTD 27.5
Rear Shock
Fox Float Remote CTD Custom Race Valved
Drivetrain
Rear Derailleur
SRAM X9 Type 2 All Mountain 10spd
Front Derailleur
SRAM X7 S3 Direct Mount 2x10spd
Shift Levers
SRAM X7 MatchMaker Triggers 2x10spd
Cassette
SRAM PG-1030 11-36T 10spd
Crank
Race Face Turbine 170-175mm 36/24T 10spd
Bottom Bracket
Race Face Press Fit Team XC
Chain
SRAM PC-1031 10spd
Wheels
Front Hub
Wheeltech SL Hi Tension Straight Pull / Precision Sealed Japanese Bearings / 24H / 15mm Axle
Rear Hub
Wheeltech SL Hi Tension Straight Pull / Precision Sealed Japanese Bearings / 28H / 12 x 142mm Axle
Rims
Wheeltech Inferno 25 27.5 by SUNringlé
Spokes
DT Swiss Champion
Tires
Schwalbe Nobby Nic Folding 27.5 x 2.35\"
Brakes
Brakes
Avid Elixir 50 XM Hydraulic Disc 180mm
Brake Levers
Avid Elixir 50 XM
Cockpit
Stem
Race Face 6° x 60-70mm
Handlebar
Race Face Evolve 3/4 Rise Ø31.8mm x 725mm x 9° Sweep
Grips
Rocky Mountain Lock On XC
Headset
Cane Creek Ten Series: IS42mm Top / 52mm Bottom Tapered
Seat
Saddle
Rocky Mountain XC Light
Seatpost
RockShox Reverb Stealth 30.9mm x 380-420mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.5 mm | 1.46 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 365 mm | 365 mm | 365 mm | 365 mm | 365 mm |
| Front Center | 667 mm | 692 mm | 714 mm | 735 mm | 761 mm |
| Rake | 40 mm | 38 mm | 38 mm | 39 mm | 38 mm |
| Trail | 110 mm | 112 mm | 112 mm | 111 mm | 112 mm |
| Stack | 575 mm | 585 mm | 594 mm | 603 mm | 617 mm |
| Reach | 368 mm | 390 mm | 408 mm | 425 mm | 446 mm |
| Top Tube Length | 538 mm | 563 mm | 583 mm | 603 mm | 628 mm |
| Seat Tube Angle | 73.6 ° | 73.6 ° | 73.6 ° | 73.6 ° | 73.6 ° |
| Seat Tube Length | 381 mm | 419 mm | 457 mm | 483 mm | 521 mm |
| Head Tube Angle | 66.6 ° | 66.6 ° | 66.6 ° | 66.6 ° | 66.6 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1093 mm | 1118 mm | 1140 mm | 1161 mm | 1187 mm |
| Bottom Bracket Drop | -10 mm | -10 mm | -10 mm | -10 mm | -10 mm |
| Standover Height | 732 mm | 732 mm | 732 mm | 732 mm | 732 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Altitude 750 MSL completes the Rockymountain Altitude model. 88 bikes variations carry this model name so far. Check out the entire range from 2013 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Altitude 750 MSL components
Fork
Rocky Mountain Altitude 750 MSL 2013 bike is equipped with the Fox Float 34 fork, and has 150mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Rocky Mountain Altitude 750 MSL bike has the Fox Float Remote CTD Custom Race Valved model installed, and has a travel of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the Altitude 750 MSL model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Rocky Mountain Altitude 750 MSL is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Altitude 750 MSL comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Rocky Mountain model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
