Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork Suntour XCE
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
137cm - 154cm
XS
151cm - 165cm
SM
160cm - 170cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 SL Alloy. Threaded BB. Zero Stack Headtube.
Suspension Fork
Suntour XCE28 DS 80mm
Drivetrain
Rear Derailleur
MicroShift Advent With Clutch
Shift Levers
MicroShift Advent 8spd
Cassette
SunRace CSM680 11-40T
Crank
Rocky Mountain Microdrive 3PC | 28T |76mm Asymmetrical BCD | Crank Length: XS-SM-MD = 170-mm | LG - XL = 175mm
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z8.3
Wheels
Front Hub
Rocky Mountain QR
Rear Hub
Shimano TX505
Rims
Rocky Mountain JR25 Tubeless | 32H | Tubeless Compatible - Tape | Valves | Sealant Not Incl
Spokes
2.0 Stainless
Tires
F: WTB Trail Boss Comp 26 x 2.25 | R: WTB Trail Boss Comp 26 x 2.25
Brakes
Brakes
Shimano TX805 | Resin Pads | F: Shimano RT10 160mm | R: Shimano RT10 160mm
Cockpit
Stem
Rocky Mountain 31.8 AM | 7° Rise | All Sizes = 40m
Handlebar
Rocky Mountain XC | 740mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Grips
Rocky Mountain Slide On XC
Headset
Rocky Mountain | Loose Ball Bearings | 1-1/8" Crown Race
Seat
Saddle
Rocky Mountain 148 Steel
Seatpost
Rocky Mountain 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.54 mm | 1.49 mm |
| Front Center | 604 mm | 626 mm | 647 mm |
| Rake | 38 mm | 39 mm | 40 mm |
| Stack | 550 mm | 585 mm | 596 mm |
| Reach | 370 mm | 379 mm | 401 mm |
| Top Tube Length | 524 mm | 549 mm | 574 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 343 mm | 381 mm | 430 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 115 mm | 135 mm | 145 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1021 mm | 1043 mm | 1064 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 712 mm | 747 mm | 777 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 137 cm | 151 cm | 160 cm |
| Rider Max Height | 154 cm | 165 cm | 170 cm |
About this model
Edge Jr 26 completes the Rockymountain Edge model. 41 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Rocky Mountain Edge Jr 12 2023 is the cheapest bike model and costs 231$. Rocky Mountain Edge Jr 26 2023 is the most expensive one and costs 699$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Mountain bikes average price
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Rocky Mountain released this model in 2023, its price was 699$. Comparing this to the average Mountain bike price, we see that the price is 13.47% higher.
Overview of components
Fork
This bike has the Suntour XCE fork installed. The fork’s travel is 80mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Edge Jr 26 2023 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 3 sizes. They vary from 137 cm – 170 cm (4.49 ft – 5.58 ft). In short, you can easily find one that suits you.
