Rocky Mountain Element C90 Shimano 2023
2023 Mountain
Estimate price |
9,699$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XTR, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Steep
142cm - 159cm
XS Slack
142cm - 159cm
SM Steep
156cm - 170cm
SM Slack
156cm - 170cm
MD Steep
167cm - 177cm
MD Slack
167cm - 177cm
LG Steep
175cm - 188cm
LG Slack
175cm - 188cm
XL Steep
185cm - 198cm
XL Slack
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | RIDE-4™ Adjustable Geometry + Suspension Rate | 120mm Travel. SMOOTHWALL™ Carbon Rear Triangle
Suspension Fork
Fox 34 Float Factory 130mm | 44mm Offset
Rear Shock
Fox Float DPS Factory | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 190x45mm | Size-Specific tune in FAQ
Drivetrain
Rear Derailleur
Shimano XTR
Shift Levers
Shimano XTR
Cassette
Shimano XTR 12s 10-51T
Crank
Race Face Next SL G5 Cinch | 32T | 30mm Spindle | Crankarm Length: All Sizes = 170mm
Bottom Bracket
Race Face BB92 30mm
Chain
Shimano XTR 12s
Wheels
Front Hub
Rocky Mountain Sealed Boost 15mm
Rear Hub
DT Swiss 350 Boost 148mm | 36T Star-Ratchet
Rims
Rocky Mountain 26XC Carbon | Tubeless Ready - Tape / Valves Incl
Spokes
DT Swiss Revolution 2.0/1.5/2.0
Tires
F: Maxxis Rekon WT 3C MaxxTerra EXO Tubeless Ready 2.4 // R: Maxxis Rekon WT 3C MaxxTerra EXO Tubeless Ready 2.4
Brakes
Brakes
Shimano XTR 2 Piston | Metal Pads | F:Shimano RT86 180mm | R:Shimano RT86 180mm
Cockpit
Stem
Rocky Mountain 35 CNC | 0° Rise | All Sizes = 50m
Handlebar
Race Face Next | XS = 760mm | SM - XL = 780mm Width | 20mm Rise | 8° Backsweep | 4° Upsweep | 35mm Clamp
Grips
ODI Elite Pro Lock On
Headset
FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Seat
Saddle
WTB Silverado Carbon 142 | Carbon Rails
Seatpost
Fox Transfer Factory Series 30.9mm | XS - SM = 125mm | MD = 150mm | LG = 175mm | XL = 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Steep | XS Slack | SM Steep | SM Slack | MD Steep | MD Slack | LG Steep | LG Slack | XL Steep | XL Slack |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.4 mm | 1.42 mm | 1.35 mm | 1.36 mm | 1.3 mm | 1.31 mm | 1.24 mm | 1.25 mm |
| Bottom Bracket Height | 336 mm | 327 mm | 338 mm | 327 mm | 338 mm | 327 mm | 338 mm | 327 mm | 338 mm | 327 mm |
| Front Center | 703 mm | 702 mm | 740 mm | 741 mm | 769 mm | 770 mm | 798 mm | 799 mm | 832 mm | 833 mm |
| Rake | 44 mm | 48 mm | 44 mm | 49 mm | 44 mm | 49 mm | 44 mm | 48 mm | 44 mm | 48 mm |
| Trail | 114 mm | 115 mm | 120 mm | 121 mm | 120 mm | 121 mm | 120 mm | 122 mm | 120 mm | 122 mm |
| Stack | 572 mm | 567 mm | 616 mm | 612 mm | 625 mm | 621 mm | 634 mm | 630 mm | 643 mm | 639 mm |
| Reach | 411 mm | 403 mm | 439 mm | 431 mm | 464 mm | 456 mm | 489 mm | 481 mm | 519 mm | 511 mm |
| Top Tube Length | 547 mm | 548 mm | 581 mm | 583 mm | 609 mm | 611 mm | 636 mm | 638 mm | 668 mm | 670 mm |
| Seat Tube Angle | 76.5 ° | 75.7 ° | 76.8 ° | 76 ° | 76.8 ° | 76 ° | 76.8 ° | 76 ° | 76.8 ° | 76 ° |
| Seat Tube Length | 355 mm | 355 mm | 380 mm | 380 mm | 420 mm | 420 mm | 445 mm | 445 mm | 480 mm | 480 mm |
| Head Tube Angle | 65.5 ° | 64.7 ° | 65.8 ° | 65 ° | 65.8 ° | 65 ° | 65.8 ° | 65 ° | 65.8 ° | 65 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 105 mm | 115 mm | 115 mm | 125 mm | 125 mm | 135 mm | 135 mm |
| Chainstay Length | 431 mm | 432 mm | 441 mm | 442 mm | 441 mm | 442 mm | 441 mm | 442 mm | 441 mm | 442 mm |
| Wheelbase | 1133 mm | 1133 mm | 1179 mm | 1179 mm | 1208 mm | 1208 mm | 1237 mm | 1237 mm | 1271 mm | 1271 mm |
| Bottom Bracket Drop | 19 mm | 28 mm | 36 mm | 47 mm | 36 mm | 47 mm | 36 mm | 47 mm | 36 mm | 47 mm |
| Standover Height | 778 mm | 775 mm | 819 mm | 816 mm | 817 mm | 814 mm | 816 mm | 812 mm | 814 mm | 810 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 142 cm | 142 cm | 156 cm | 156 cm | 167 cm | 167 cm | 175 cm | 175 cm | 185 cm | 185 cm |
| Rider Max Height | 159 cm | 159 cm | 170 cm | 170 cm | 177 cm | 177 cm | 188 cm | 188 cm | 198 cm | 198 cm |
About this model
Element C90 Shimano completes the Rockymountain Element model. Rocky Mountain released 77 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Rocky Mountain Element A10 Shimano 2023 is the cheapest bike model and costs 2699$. Rocky Mountain Element Carbon 90 2023 is the most expensive one and costs 9699$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 9699$. In conclusion, this bike price is 251.16% more expensive than the price of the average Trail bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 34 model. The travel on this model is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Rocky Mountain Element C90 Shimano bike has the Fox Float DPS Factory | Sealed model installed, and has a travel of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Element C90 Shimano bike is equipped with the 27.5″ carbon model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Rocky Mountain Element C90 Shimano has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 10 sizes available for this model. Rider height can be anywhere between 142 cm – 198 cm (4.66 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Element C90 Shimano. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
