Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 200mm -
Travel Rear 200mm -
Fork RockShox Domain
-
Groupset X5, Race Face -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FORM™ Alloy Custom Hydroformed Frame World Cup Race Geometry 1.5\" Head Tube ISCG03 Tabs 150x12mm Thru Axle Maxle Compatible
Suspension Fork
RockShox Domain Dual Crown R
Rear Shock
RockShox Kage R
Drivetrain
Rear Derailleur
SRAM X5 9spd
Front Derailleur
N/A
Shift Levers
SRAM X5 Triggers 9spd
Cassette
Shimano HG20 11-34T
Crank
Race Face Chester 165mm 36T / e*Thirteen LS1+
Bottom Bracket
Race Face X-Type 83mm
Chain
KMC X9 9spd
Wheels
Front Hub
Wheeltech AM Sealed 20mm Axle
Rear Hub
Wheeltech DH Sealed 150 x 12mm Maxle
Rims
Wheeltech MTX 31 by SUNringlé
Spokes
DT Swiss Champion
Tires
Maxxis Minion DHF 60a 2.5\"
Brakes
Brakes
Avid Elixir 3 Hydraulic Disc 200mm
Brake Levers
Avid Elixir 3
Cockpit
Stem
Rocky Mountain DH 10° x 40mm
Handlebar
Answer Pro Taper Ø31.8mm x 780mm x 8°
Grips
Rocky Mountain Lock On DH
Headset
Cane Creek Ten Series: ZS49mm Reducer
Seat
Saddle
Rocky Mountain XC Light
Seatpost
Rocky Mountain SL 30.9mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.46 mm | 1.37 mm |
| Bottom Bracket Height | 356 mm | 356 mm | 356 mm |
| Front Center | 705 mm | 731 mm | 756 mm |
| Rake | 34 mm | 34 mm | 34 mm |
| Trail | 129 mm | 129 mm | 129 mm |
| Stack | 593 mm | 593 mm | 593 mm |
| Reach | 381 mm | 407 mm | 432 mm |
| Top Tube Length | 554 mm | 580 mm | 606 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406 mm | 432 mm | 457 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1156 mm | 1182 mm | 1207 mm |
| Bottom Bracket Drop | -13 mm | -13 mm | -13 mm |
| Standover Height | 730 mm | 740 mm | 754 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Flatline Park completes the Rockymountain Flatline model. There are 5 bikes that carry this model name. Take a sneak peek at all Rockymountain Flatline bikes models from 2013, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Downhill bikes
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, this doesn’t mean that if you spend less money on a Downhill bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Flatline Park components
Fork
The RockShox Domain is included from the factory. It has a travel distance of 200mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rocky Mountain Flatline Park bike has the RockShox Kage R model installed, and has a travel of 200mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Flatline Park 2013 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Rocky Mountain Flatline Park is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Flatline Park comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
