Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Altus -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Alloy. Threaded BB. Zero Stack Tapered Headtube
Suspension Fork
SR Suntour XCM 100mm (XS: 80mm)
Drivetrain
Rear Derailleur
Shimano Altus
Shift Levers
Shimano Altus
Cassette
SunRace CSM680 11-40T
Crank
Rocky Mountain Microdrive 28T
Bottom Bracket
FSA Sealed Cartridge Bearing
Chain
KMC Z-72
Pedals
Nylon Platform
Wheels
Front Hub
Shimano TX505
Rear Hub
Shimano TX505
Rims
Alex MD19
Spokes
2.0 Stainless
Tires
F: Maxxis Ardent 29 x 2.25 / R: Maxxis Ardent 29 x 2.25
Brakes
Brakes
Shimano MT200
Cockpit
Stem
Rocky Mountain AM
Handlebar
Rocky Mountain XC 740mm
Grips
Rocky Mountain Lock On Light
Headset
FSA No. 57B-1
Seat
Saddle
WTB Volt
Seatpost
Rocky Mountain 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.61 mm | 1.51 mm | 1.48 mm | 1.45 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 648 mm | 630 mm | 652 mm | 676 mm | 699 mm |
| Rake | 63 mm | 44 mm | 43 mm | 42 mm | 43 mm |
| Trail | 73 mm | 88 mm | 89 mm | 90 mm | 89 mm |
| Stack | 603 mm | 621 mm | 620 mm | 634 mm | 648 mm |
| Reach | 382 mm | 386 mm | 410 mm | 429 mm | 446 mm |
| Top Tube Length | 556 mm | 576 mm | 598 mm | 621 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 355 mm | 393 mm | 431 mm | 469 mm | 508 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 453 mm | 453 mm | 453 mm | 453 mm | 453 mm |
| Wheelbase | 1095 mm | 1077 mm | 1099 mm | 1123 mm | 1146 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 725 mm | 744 mm | 758 mm | 782 mm | 814 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fusion 10 completes the Rockymountain Fusion model. There are 35 bikes that carry this model name. You can easily view all of the Rockymountain Fusion bikes models from 2019, here.
Model range prices
Rocky Mountain Fusion 10 2019 is the most affordable bike of this model and has a price of 699$. On the other hand, Rocky Mountain Fusion 40 2019, is the most expensive and costs 1119$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 699$. Comparing the average cost of a Crosscountry bike to this one, you will see that Fusion 10 price is 172.53% lower.
Fusion 10 components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Fusion 10 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Rocky Mountain Fusion 10 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Fusion 10 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
