Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox
-
Groupset SLX, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Series Custom Hydroformed Alloy Frame Threaded BB ZeroStack 1-1/8\" Headtube Rack and Fender Mounts
Suspension Fork
RockShox XC30 TK
Drivetrain
Rear Derailleur
Shimano SLX 9spd
Front Derailleur
Shimano Acera 31.8mm 9spd
Shift Levers
Shimano Deore Rapid Fire 9spd
Cassette
Shimano HG30 11-34T 9spd
Crank
Shimano Deore 170-175mm 44/32/22T 9spd
Bottom Bracket
Shimano Deore Hollowtech
Chain
KMC X9 9spd
Wheels
Front Hub
Shimano HB-M595 Centerlock / 9 x 100mm QR
Rear Hub
Shimano FH-M595 Centerlock / 10 x 135mm QR
Rims
Wheeltech SX17 By WTB
Spokes
Stainless
Tires
Continental Race King 26\" x 2.2\"
Brakes
Brakes
Shimano BR-M446 Hydraulic Disc 160mm
Brake Levers
Shimano BL-M446
Cockpit
Stem
Rocky Mountain L7 7° x 60-110mm
Handlebar
Rocky Mountain Five15 XC Ø31.8mm x 660mm x 5° Sweep
Grips
Rocky Mountain XC Kraton
Headset
Cane Creek Five Series: ZS44mm
Seat
Saddle
Rocky Mountain XC
Seatpost
Rocky Mountain L2B 27.2mm x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 598 mm | 611 mm | 631 mm | 646 mm | 656 mm | 671 mm | 683 mm |
| Top Tube Length | 519 mm | 534 mm | 559 mm | 579 mm | 594 mm | 614 mm | 626 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 343 mm | 381 mm | 419 mm | 457 mm | 483 mm | 521 mm | 559 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 130 mm | 150 mm | 175 mm | 175 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1015 mm | 1028 mm | 1048 mm | 1063 mm | 1073 mm | 1088 mm | 1100 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 694 mm | 711 mm | 728 mm | 750 mm | 771 mm | 793 mm | 816 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
Model Overview
Fusion 26 is a Rockymountain Fusion model. Rocky Mountain launched 35 bikes of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Fusion 26 components
Fork
Rocky Mountain Fusion 26 2013 bike is equipped with the RockShox fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Rocky Mountain Fusion 26 2013, has a 26″ aluminum model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fusion 26 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 157 cm – 204 cm (5.15 ft – 6.69 ft). In short, it won’t be difficult to find the right one for you.
