Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Float 32
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FORM™ Alloy Custom Hydroformed Frame ABC™ Pivots Tapered Head Tube Press Fit BB Internal Cable Routing Internal \"Stealth\" Dropper Post Routing Internal Shock Remote Routing ISCG05 Tabs RIDE-9™ System Adjustable Geometry & Suspension Rate
Suspension Fork
Fox 32 Float 29 130 FIT CTD
Rear Shock
Fox Float Remote CTD Custom Trail Valved
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus 10spd
Front Derailleur
Shimano XT E Mount 2x10spd
Shift Levers
Shimano XT Rapid Fire 2x10spd
Cassette
Shimano HG81 11-36T 10spd
Crank
Race Face Turbine 170-175mm 36/24T 2x10spd
Bottom Bracket
Race Face Press Fit Team XC
Chain
Shimano HG74 10spd
Wheels
Front Hub
DT Swiss M 1.6 Straight Pull 15mm Axle
Rear Hub
DT Swiss M 1.6 Straight Pull / Star Ratchet Freehub / 12 x 142mm
Rims
DT Swiss M 1.6 Tubeless Ready
Spokes
DT Swiss Competition
Tires
Continental Folding F: Mountain King 29\" x 2.2\" / R: X King 29\" x 2.2\"
Brakes
Brakes
Avid Elixir 90 XM Hydraulic Disc 180mm
Brake Levers
Avid Elixir 90 XM
Cockpit
Stem
Race Face Turbine CNC 6° x 60-90mm
Handlebar
Race Face Turbine 3/4 Rise Ø31.8mm x 725mm x 9° Sweep
Grips
Rocky Mountain Lock On XC
Headset
Cane Creek Forty Series: ZS44mm Top / ZS56mm Bottom Tapered
Seat
Saddle
Rocky Mountain XC Light
Seatpost
RockShox Reverb 30.9mm x 380-420mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.54 mm | 1.49 mm | 1.44 mm | 1.4 mm |
| Bottom Bracket Height | 334 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 661 mm | 685 mm | 709 mm | 734 mm | 761 mm |
| Rake | 46 mm | 45 mm | 44 mm | 44 mm | 43 mm |
| Trail | 104 mm | 105 mm | 106 mm | 106 mm | 107 mm |
| Stack | 599 mm | 608 mm | 618 mm | 627 mm | 641 mm |
| Reach | 372 mm | 394 mm | 414 mm | 436 mm | 458 mm |
| Top Tube Length | 547 mm | 571 mm | 594 mm | 619 mm | 644 mm |
| Seat Tube Angle | 73.7 ° | 73.7 ° | 73.7 ° | 73.7 ° | 73.7 ° |
| Seat Tube Length | 394 mm | 432 mm | 470 mm | 508 mm | 546 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1104 mm | 1128 mm | 1152 mm | 1177 mm | 1204 mm |
| Bottom Bracket Drop | 40 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 730 mm | 730 mm | 730 mm | 730 mm | 730 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
Instinct 970 belongs to the Rockymountain Instinct model. There are 89 bikes that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Instinct 970 components
Fork
Rocky Mountain Instinct 970 2013 bike is equipped with the Fox Float 32 fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Instinct 970 has a rear shock with a travel of 130mm. The model Fox Float Remote CTD Custom Trail Valved is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Instinct 970 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Rocky Mountain Instinct 970 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the Instinct 970. Therefore, climbing or descending will be a breeze.
