Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Alloy. Threaded BB. Zero Stack Tapered Headtube. Dropper Post Compatible.
Suspension Fork
Suntour XCM DS 120mm
Drivetrain
Rear Derailleur
Shimano Altus 8 Spd
Shift Levers
Shimano Altus
Cassette
SunRace CSM680 11-40T 8 Spd
Crank
Rocky Mountain Microdrive 28T
Bottom Bracket
FSA Sealed Cartridge Bearing
Chain
KMC Z8.3
Pedals
Nylon Platform
Wheels
Front Hub
Shimano TX505
Rear Hub
Shimano TX505
Rims
WTB ST i23 TCS Tubeless
Spokes
2.0 Stainless
Tires
WTB Vigilante Comp 27.5 x 2.3 Front WTB Ranger Comp 27.5 x 2.25 Rear
Brakes
Brakes
Shimano MT200 2 Piston
Brake Levers
Shimano MT200
Cockpit
Stem
Rocky Mountain XC
Handlebar
Rocky Mountain XC 740mm
Grips
Rocky Mountain Lock On Light
Headset
FSA No. 57B-1
Seat
Saddle
WTB Volt Race 142
Seatpost
Rocky Mountain 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.39 mm | 1.31 mm | 1.25 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 675 mm | 703 mm | 732 mm | 766 mm |
| Rake | 45 mm | 44 mm | 43 mm | 44 mm |
| Trail | 109 mm | 110 mm | 111 mm | 110 mm |
| Stack | 581 mm | 582 mm | 586 mm | 595 mm |
| Reach | 392 mm | 420 mm | 448 mm | 477 mm |
| Top Tube Length | 558 mm | 586 mm | 615 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 352 mm | 392 mm | 432 mm | 470 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 110 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1099 mm | 1127 mm | 1156 mm | 1190 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 750 mm | 757 mm | 769 mm | 784 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Soul 10 completes the Rockymountain Soul model. There are 39 bikes that carry this model name. Take a sneak peek at all Rockymountain Soul bikes models from 2020, by clicking here.
Model range prices
Rocky Mountain Soul Jr 20 2020 is the most economical model, with a starting price of 519$. Rocky Mountain Soul 20 2020 on the other hand costs 789$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2020 and its price was 699$. Comparing this to the average Trail bike price, we see that the price is 295.14% smaller.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on Soul 10 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Soul 10 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Soul 10 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
