Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Alloy. Threaded BB. Zero Stack Tapered Headtube. Dropper Post Compatible.
Suspension Fork
Suntour XCM DS 120mm
Drivetrain
Rear Derailleur
MicroShift Advent 1x9 With Clutch
Shift Levers
MicroShift Xpress Plus 9spd
Cassette
MicroShift CS-H093 11-42T
Crank
Rocky Mountain Microdrive 28T
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC X10-1
Pedals
Nylon Platform
Wheels
Front Hub
Shimano TX505
Rear Hub
Shimano TX505 QR
Rims
Rocky Mountain TR25 Tubeless | Tubeless Compatible - Tape | Valves | Sealant Not Incl
Spokes
2.0 Stainless
Tires
F: Kenda Amrak 27.5 x 2.4 // R: Kenda Amrak 27.5 x 2.4
Brakes
Brakes
Shimano MT200 2 Piston | Organic Pads | Shimano RT10 160mm F Rotor | Shimano RT10 160mm R Rotor
Cockpit
Stem
Rocky Mountain XC | 7° Rise | All Sizes = 40mm
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8mm Clamp
Grips
Rocky Mountain Lock On Light
Headset
FSA Orbit NO.57B-1 | 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | Reducer Crown Race
Seat
Saddle
WTB Volt | Steel Rails | 142mm Width
Seatpost
Rocky Mountain 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.41 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 684 mm | 709 mm | 733 mm | 763 mm |
| Rake | 40 mm | 40 mm | 39 mm | 40 mm |
| Trail | 114 mm | 114 mm | 116 mm | 114 mm |
| Stack | 588 mm | 588 mm | 592 mm | 601 mm |
| Reach | 393 mm | 418 mm | 441 mm | 466 mm |
| Top Tube Length | 557 mm | 582 mm | 606 mm | 634 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 345 mm | 380 mm | 420 mm | 445 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 110 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1106 mm | 1131 mm | 1155 mm | 1185 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 744 mm | 750 mm | 763 mm | 772 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Soul 10 belongs to the Rockymountain Soul model. 39 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Rocky Mountain Soul Jr 20 2021 is the cheapest bike model and costs 599$. Rocky Mountain Soul 20 2021 is the most expensive one and costs 879$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 779$. Comparing the average cost of a Trail bike to this one, you will see that Soul 10 price is 254.56% smaller.
Soul 10 components
Fork
Rocky Mountain Soul 10 2021 bike is equipped with the SunTour XCM fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Soul 10 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Soul 10 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Soul 10 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
