Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCR 32
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Alloy. Threaded BB. Zero Stack Tapered Headtube
Suspension Fork
Suntour XCR 32 LO 120mm
Drivetrain
Rear Derailleur
Shimano Altus
Shift Levers
Shimano Altus
Cassette
SunRace CSM980 11-40T
Crank
Rocky Mountain Microdrive 28T
Bottom Bracket
FSA Sealed Cartridge Bearing
Chain
KMC X9
Pedals
Alloy Platform
Wheels
Front Hub
Shimano TX505
Rear Hub
Shimano TX505
Rims
Alex MD19
Spokes
2.0 Stainless
Tires
F: Maxxis Forekaster 27.5 x 2.35 / R: Maxxis Forekaster 27.5 x 2.35
Brakes
Brakes
Shimano MT201
Cockpit
Stem
Rocky Mountain AM
Handlebar
Rocky Mountain XC 740mm
Grips
Rocky Mountain Lock On Light
Headset
FSA No. 57B-1
Seat
Saddle
WTB Volt
Seatpost
Rocky Mountain 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.61 mm | 1.5 mm | 1.45 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 643 mm | 670 mm | 695 mm | 721 mm | 742 mm | 769 mm |
| Rake | 52 mm | 53 mm | 52 mm | 54 mm | 52 mm | 54 mm |
| Trail | 94 mm | 93 mm | 94 mm | 92 mm | 94 mm | 92 mm |
| Stack | 571 mm | 595 mm | 595 mm | 604 mm | 614 mm | 624 mm |
| Reach | 354 mm | 370 mm | 396 mm | 417 mm | 435 mm | 456 mm |
| Top Tube Length | 529 mm | 554 mm | 579 mm | 604 mm | 624 mm | 649 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 343 mm | 381 mm | 430 mm | 457 mm | 483 mm | 521 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1057 mm | 1085 mm | 1110 mm | 1136 mm | 1157 mm | 1184 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 764 mm | 799 mm | 802 mm | 811 mm | 824 mm | 841 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
Soul 20 is part of the Rockymountain Soul model. Rocky Mountain released 39 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Rocky Mountain Soul 10 2019 is the cheapest bike model and costs 645$. Rocky Mountain Soul 20 2019 is the most expensive one and costs 799$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Rocky Mountain Soul 20 price was 799$. In conclusion, this bike price is 245.68% lower than the price of the average Trail bike.
Soul 20 components
Fork
The fork installed on this bike is the SunTour XCR 32 model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Soul 20 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
