Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
160cm - 170cm
MD
167cm - 180cm
LG
177cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rocky Mountain 6061 Alloy. Threaded BB. Zero Stack Tapered Headtube. Dropper Post Compatible. Rear Triangle
Suspension Fork
Suntour XCM34 Boost 120mm
Drivetrain
Rear Derailleur
Shimano Deore 10spd
Shift Levers
Shimano Deore 10spd
Cassette
Sunrace CSMS2 11-46T
Crank
Rocky Mountain Microdrive 30T
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC X10-1
Wheels
Front Hub
Shimano MT400 | 15mm Boost
Rear Hub
Shimano TX505
Rims
Rocky Mountain TR30 Tubeless | 32H | Tubeless Compatible - Tape and Valves Not Incl
Spokes
2.0 Stainless
Tires
F - Kenda Amrak 27.5 x 2.4 | R - Kenda Amrak 27.5 x 2.4
Brakes
Brakes
Shimano MT4100 2 Piston | Resin Pads
Cockpit
Stem
Rocky Mountain XC
Handlebar
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
Grips
Rocky Mountain Lock On Light
Headset
Rocky Mountain | Loose Ball Bearings | 1.5" Crown Race
Seat
Saddle
Rocky Mountain 148 Steel
Seatpost
Rocky Mountain 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.41 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 684 mm | 709 mm | 733 mm | 763 mm |
| Rake | 40 mm | 40 mm | 39 mm | 40 mm |
| Trail | 114 mm | 114 mm | 116 mm | 114 mm |
| Stack | 588 mm | 588 mm | 592 mm | 601 mm |
| Reach | 393 mm | 418 mm | 441 mm | 466 mm |
| Top Tube Length | 557 mm | 582 mm | 606 mm | 634 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 345 mm | 380 mm | 420 mm | 445 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 95 mm | 95 mm | 100 mm | 110 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1106 mm | 1131 mm | 1155 mm | 1185 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 744 mm | 750 mm | 763 mm | 772 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 160 cm | 167 cm | 177 cm |
| Rider Max Height | 165 cm | 170 cm | 180 cm | 188 cm |
About this model
Soul 20 is a Rockymountain Soul model. 39 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Rocky Mountain Soul Jr 20 2022 is the most affordable bike of this model and has a price of 639$. On the other hand, Rocky Mountain Soul 20 2022, is the most expensive and costs 1019$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2022 and its price was 1019$. If we compare this with the average Trail bike cost we notice that the price is 171.05% lower.
Soul 20 components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Rocky Mountain Soul 20 2022, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Rocky Mountain Soul 20 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 188 cm (4.99 ft – 6.17 ft). In conclusion, finding one for you shouldn’t be a problem.
