Rocky Mountain Vertex 930 2016
2016 Mountain
Estimate price |
1,499$
Weight | 11.97 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Manitou
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FORM Custom Hydroformed Alloy. Press Fit BB. Zero Stack Tapered Headtube. Internal Cable Routing
Suspension Fork
Manitou Marvel Comp TS Air. 100mm (XS: 80mm). Compression / Lockout / Rebound / Tapered Steerer
Drivetrain
Rear Derailleur
Shimano XT 10spd
Front Derailleur
Shimano Deore 31.8mm 10spd
Shift Levers
Shimano SLX I-Spec Rapid Fire 10spd
Cassette
Shimano HG50 11-36T 10spd
Crank
Shimano M617 170-175mm 36/22T 2x10spd
Bottom Bracket
Shimano SMBB52 Press Fit
Chain
Shimano HG54 10spd
Wheels
Front Hub
Shimano RM66 / Centerlock / 32H
Rear Hub
Shimano RM66 / Centerlock / 32H
Rims
Wheeltech SX17 29 by WTB
Spokes
Stainless
Tires
Maxxis Ikon Folding 29\" x 2.2\"
Brakes
Brakes
Shimano M506 Hydraulic Disc 180/160mm
Brake Levers
Shimano M506 I-Spec Shifter Mount
Cockpit
Stem
RMB 7° x 70-90mm
Handlebar
Rocky Mountain Zero9 Flat 31.8mm x 700mm x 9° Sweep
Grips
Rocky Mountain XC Kraton
Headset
FSA Orbit NO.57E: ZS44mm Top / ZS56mm Bottom Tapered
Seat
Saddle
WTB Volt
Seatpost
Rocky Mountain SL 27.2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.57 mm | 1.5 mm | 1.47 mm | 1.44 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 639 mm | 638 mm | 660 mm | 684 mm | 707 mm |
| Rake | 53 mm | 51 mm | 50 mm | 50 mm | 50 mm |
| Trail | 83 mm | 80 mm | 81 mm | 81 mm | 81 mm |
| Stack | 593 mm | 613 mm | 618 mm | 632 mm | 646 mm |
| Reach | 387 mm | 390 mm | 411 mm | 430 mm | 448 mm |
| Top Tube Length | 556 mm | 576 mm | 598 mm | 621 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 355 mm | 394 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 69.5 ° | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 100 mm | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 441 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1074 mm | 1071 mm | 1093 mm | 1117 mm | 1140 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 725 mm | 744 mm | 758 mm | 782 mm | 814 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Vertex 930 completes the Rockymountain Vertex model. Rocky Mountain launched 67 bikes of this model so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Rocky Mountain Vertex 20 2016 is the most economical model, with a starting price of 729$. Rocky Mountain Vertex 990 RSL 2016 on the other hand costs 4799$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Rocky Mountain released this model in 2016, its price was 1499$. Comparing the average cost of a Crosscountry bike to this one, you will see that Vertex 930 price is 27.08% smaller.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Vertex 930 weighs 11.97 kg (26.39 lbs) and is slightly lighter than the average. To sum up, it’s 3.59% lighter than the average weight of Crosscountry bikes.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Vertex 930 components
Fork
Rocky Mountain Vertex 930 2016 bike is equipped with the Manitou fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Rocky Mountain Vertex 930 2016, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Vertex 930 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Rocky Mountain Vertex 930 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
