Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Float 32
-
Groupset X9, X7 -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SMOOTHWALL™ Carbon Tapered Head Tube Press Fit BB Internal Cable Routing
Suspension Fork
Fox 32 Float 29 100 CTD
Drivetrain
Rear Derailleur
SRAM X9 10spd
Front Derailleur
SRAM X7 34.9mm 2x10spd
Shift Levers
SRAM X7 Matchmaker Triggers 2x10spd
Cassette
SRAM PG-1030 12-36T 10spd
Crank
SRAM S1400 170-175mm 38/24T 2x10spd
Bottom Bracket
SRAM Press Fit GXP
Chain
SRAM PC-1031 10spd
Wheels
Front Hub
Wheeltech SL Hi Tension Straight Pull / Precision Sealed Japanese Bearings / 24H / 15mm Axle
Rear Hub
Wheeltech SL Hi Tension Straight Pull / Precision Sealed Japanese Bearings / 28H / 12 x 142mm Axle
Rims
Wheeltech Inferno 23 by SUNringlé
Spokes
DT Swiss Champion Straight Pull
Tires
Continental Race King Folding 29\" x 2.2\"
Brakes
Brakes
Avid Elixir 50 XR Hydraulic Disc 180/160mm
Brake Levers
Avid Elixir 50 XR MatchMaker
Cockpit
Stem
Rocky Mountain L7 7° x 60-100mm
Handlebar
Rocky Mountain Zero9 Flat Ø31.8mm x 700mm x 9° Sweep
Grips
Rocky Mountain Lock On XC
Headset
Cane Creek Ten Series: IS42mm Top / IS52mm Bottom Tapered
Seat
Saddle
Rocky Mountain XC Light
Seatpost
Rocky Mountain SL 27.2 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.48 mm | 1.45 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 638 mm | 660 mm | 683 mm | 707 mm |
| Rake | 50 mm | 50 mm | 49 mm | 50 mm |
| Trail | 81 mm | 81 mm | 82 mm | 81 mm |
| Stack | 600.9 mm | 605.7 mm | 619.8 mm | 633.9 mm |
| Reach | 378.4 mm | 399 mm | 417.7 mm | 436.4 mm |
| Top Tube Length | 564 mm | 586 mm | 609 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1059 mm | 1081 mm | 1104 mm | 1128 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 732 mm | 746 mm | 770 mm | 802 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Vertex 950 RSL is part of the Rockymountain Vertex model. Rocky Mountain launched 67 bikes of this model so far. Take a sneak peek at all Rockymountain Vertex bikes models from 2013, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
This bike has the Fox Float 32 fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Vertex 950 RSL model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Vertex 950 RSL has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Rocky Mountain Vertex 950 RSL bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
