Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 29" -
Suspension Rigid
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SMOOTHWALL™ Carbon Tapered Head Tube Press Fit BB Internal Cable Routing
Suspension Fork
100mm Recommended
Drivetrain
Front Derailleur
34.9mm Bottom Pull Compatible
Bottom Bracket
BB 92 Press Fit Compatible
Wheels
Rear Hub
Shimano E-Thru 142x12mm Axle Included
Cockpit
Headset
IS42mm Top / 52mm Bottom Tapered Compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.52 mm | 1.48 mm | 1.45 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm |
| Front Center | 638 mm | 660 mm | 683 mm | 707 mm |
| Rake | 50 mm | 50 mm | 49 mm | 50 mm |
| Trail | 81 mm | 81 mm | 82 mm | 81 mm |
| Stack | 600.9 mm | 605.7 mm | 619.8 mm | 633.9 mm |
| Reach | 378.4 mm | 399 mm | 417.7 mm | 436.4 mm |
| Top Tube Length | 564 mm | 586 mm | 609 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 470 mm | 508 mm |
| Head Tube Angle | 70.25 ° | 70.25 ° | 70.25 ° | 70.25 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1059 mm | 1081 mm | 1104 mm | 1128 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 732 mm | 746 mm | 770 mm | 802 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Vertex 999 RSL Frame belongs to the Rockymountain Vertex model. Rocky Mountain released 67 frames variations of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry frames
Our math shows that the average cost of a dependable Crosscountry frame is 1689$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry frame. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
Internal Cable Routing
It’s also important to mention the internal cable routing that this frame has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Vertex 999 RSL Frame components
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
