Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset Apex 1, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TANGE CHAMPION DOUBLE BUTTED CRO-MO STEEL FRAME
Suspension Fork
TWINTIP 2.0 CARBON
Drivetrain
Rear Derailleur
SRAM APEX 1 TYPE 2.1
Shift Levers
SRAM APEX 1
Cassette
SUNRACE CSMS7 11-42 11 SPEED
Crank
FSA OMEGA EXO 42T 170MM(S), 172.5MM(M,L), 175MM (XL)
Bottom Bracket
BSA 68mm
Chain
SRAM PC1130
Wheels
Front Hub
RONDO SUPERLIGHT SEALED BEARINGS
Rear Hub
RONDO SUPERLIGHT SEALED BEARINGS
Rims
RONDO ALUMINIUM 622-23 TUBELESS COMPATIBLE* *tubeless tape, valve and sealant not included
Tires
WTB NANO 29 X 2.1
Brakes
Brakes
TRP SPYRE
Cockpit
Stem
RONDO 60MM(S,M), 80MM(L,XL)
Handlebar
RONDO BOOMERANG 440MM(S,M), 460MM(L,XL)
Grips
VELO COMFORT TAPE
Seat
Saddle
FABRIC SCOOP FLAT
Seatpost
RONDO 350 X 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | MD | LG | LG | XL | XL | HI | LO |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.08 mm | 1.1 mm | 1.07 mm | 1.1 mm | 1.07 mm | 1.07 mm | 1.41 mm | 1.45 mm |
| Front Center | 802 mm | 795 mm | 820 mm | 810 mm | 835 mm | 835 mm | 644 mm | 636 mm |
| Rake | 21 mm | 26 mm | 16 mm | 21 mm | 7 mm | 21 mm | 55 mm | 45 mm |
| Trail | 85 mm | 74 mm | 90 mm | 80 mm | 99 mm | 80 mm | 63 mm | 79 mm |
| Stack | 648 mm | 656 mm | 664 mm | 672 mm | 681 mm | 681 mm | 578 mm | 583 mm |
| Reach | 602 mm | 596 mm | 620 mm | 612 mm | 639 mm | 634 mm | 410 mm | 402 mm |
| Seat Tube Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 470 mm | 470 mm |
| Head Tube Angle | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 70.8 ° | 70 ° |
| Head Tube Length | 490 mm | 490 mm | 510 mm | 510 mm | 530 mm | 530 mm | 140 mm | 140 mm |
| Wheelbase | 839 mm | 842 mm | 857 mm | 857 mm | 872 mm | 882 mm | 1066 mm | 1060 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 86 mm | 80 mm |
| Standover Height | 586 mm | 584 mm | 601 mm | 599 mm | 621 mm | 619 mm | 776 mm | 783 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
BOGAN completes the Rondo Bogan model. Rondo launched 7 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on BOGAN are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Rondo BOGAN is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
