Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS High
150cm - 166cm
XS Low
150cm - 166cm
SM High
164cm - 174cm
SM Low
164cm - 174cm
MD High
171cm - 181cm
MD Low
171cm - 181cm
LG High
178cm - 188cm
LG Low
178cm - 188cm
XL High
185cm - 194cm
XL Low
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RONDO RUUT V2 ALU
Suspension Fork
RONDO RUUT V2 TWINTIP CARBON
Drivetrain
Rear Derailleur
MICROSHIFT SWORD
Front Derailleur
-
Shift Levers
MICROSHIFT SWORD
Cassette
MICROSHIFT 11-48 10 SPEED
Crank
RONDO DIRECT 42T 160 (XS), 170MM(S), 172.5MM(M,L), 175MM (XL)
Bottom Bracket
PF 86
Chain
KMC X10
Wheels
Front Hub
RONDO SUPERLIGHT SEALED BEARINGS
Rear Hub
RONDO SUPERLIGHT SEALED BEARINGS
Rims
RONDO ALUMINIUM 622-21/584-21(XS)
Tires
WTB NANO 700C X 40 / PIRELLI CINTURATO H 650 B X 45
Brakes
Brakes
REVER MCX
Cockpit
Stem
RONDO 60MM (XS) 80MM(S), 90MM(M,L), 110MM(XL)
Handlebar
RONDO FLARE 400MM (XS), 420MM(S), 440MM(M,L), 460MM(XL)
Grips
Selle Italia Comfort Tape
Headset
UPPER STACK: IS 42 / 28,6 LOWER STACK: IS 52 / 40 SHIS
Seat
Saddle
SELLE ITALIA MODEL X
Seatpost
RONDO 350 X 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | XS Low | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.4 mm | 1.39 mm | 1.43 mm | 1.42 mm | 1.46 mm | 1.46 mm | 1.5 mm | 1.48 mm | 1.52 mm |
| Front Center | 596 mm | 588 mm | 601 mm | 591 mm | 606 mm | 597 mm | 625 mm | 615 mm | 638 mm | 630 mm |
| Rake | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm | 55 mm | 45 mm |
| Trail | 58 mm | 72 mm | 50 mm | 69 mm | 47 mm | 63 mm | 47 mm | 64 mm | 47 mm | 64 mm |
| Stack | 515 mm | 518 mm | 530 mm | 535 mm | 552 mm | 557 mm | 581 mm | 586 mm | 600 mm | 605 mm |
| Reach | 377 mm | 370 mm | 380 mm | 373 mm | 389 mm | 381 mm | 399 mm | 391 mm | 405 mm | 399 mm |
| Top Tube Length | 527 mm | 529 mm | 535 mm | 537 mm | 550 mm | 552 mm | 568 mm | 570 mm | 578 mm | 584 mm |
| Seat Tube Angle | 73.7 ° | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 73 ° | 73.8 ° | 73 ° |
| Seat Tube Length | 450 mm | 450 mm | 475 mm | 475 mm | 510 mm | 510 mm | 540 mm | 540 mm | 570 mm | 570 mm |
| Head Tube Angle | 70.7 ° | 70 ° | 71.3 ° | 70.5 ° | 72.3 ° | 71.5 ° | 72.3 ° | 71.5 ° | 72.3 ° | 71.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 110 mm | 130 mm | 130 mm | 160 mm | 160 mm | 180 mm | 180 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1005 mm | 998 mm | 1009 mm | 1000 mm | 1014 mm | 1006 mm | 1033 mm | 1024 mm | 1046 mm | 1039 mm |
| Bottom Bracket Drop | 70 mm | 65 mm | 74 mm | 70 mm | 74 mm | 70 mm | 74 mm | 70 mm | 73 mm | 70 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 150 cm | 150 cm | 164 cm | 164 cm | 171 cm | 171 cm | 178 cm | 178 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 181 cm | 181 cm | 188 cm | 188 cm | 194 cm | 194 cm |
About this model
RUUT AL3 completes the Rondo Ruut model. Rondo released 56 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Rondo RUUT AL3 2023 is the most economical model, with a starting price of 1757$. Rondo RUUT CF1 2023 on the other hand costs 4658$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 1757$. In conclusion, this bike price is 40.13% smaller than the price of the average Gravel bike.
Overview of components
Fork material
RUUT AL3 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the RUUT AL3 bike is equipped with the aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Rondo RUUT AL3 bike has 10 sizes, in the range of 150 cm – 194 cm (4.92 ft – 6.36 ft). In short, you can easily find one that suits you.
