Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REVEAL AL, matt black 45cm-27.5
Suspension Fork
REVEAL AL, matt black
Drivetrain
Rear Derailleur
Shimano 105, RD7000GS, 11-speed, black
Front Derailleur
Shimano 105, FD-7000-F black
Cassette
Shimano CS-HG700, 11-speed, 11-34
Crank
Shimano 105, FC7000 50/34, black 170mm
Chain
Shimano CN-HG601 118 links
Pedals
Pedals are not included and must be ordered separately
Wheels
Rims
ROSE R25 | Newmen hubs | inner rim width 19mm | 24 spokes | approx. 1590g for 700c | TLR 27,5"
Tires
Continental Ultra Sport III Performance, black 650x28B
Brakes
Brakes
Shimano 105, ST-R7025 / BR-R7070, black
Cockpit
Stem
ROSE ALR, black sand 80mm
Handlebar
Ritchey Road Comp Streem II, black/matt 40cm
Seat
Saddle
Rose Edition by Selle Italia, black
Seatpost
Ritchey WTB, 350mm, black 27,2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 48cm | 51cm | 53cm | 55cm | 57cm | 59cm | 61cm | 63cm | 65cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.38 mm | 1.43 mm | 1.44 mm | 1.46 mm | 1.49 mm | 1.49 mm | 1.5 mm | 1.51 mm | 1.51 mm |
| Front Center | 566 mm | 578 mm | 580.5 mm | 595.5 mm | 601.5 mm | 601.5 mm | 611 mm | 621.5 mm | 634 mm | 647.5 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 62 mm | 53 mm | 53 mm | 56 mm | 56 mm | 53 mm | 51 mm | 50 mm | 49 mm | 47 mm |
| Stack | 496 mm | 515 mm | 536 mm | 551 mm | 566 mm | 584 mm | 594.5 mm | 611.5 mm | 630 mm | 647 mm |
| Reach | 368 mm | 374 mm | 376 mm | 381.5 mm | 386.5 mm | 391.5 mm | 400 mm | 408 mm | 418.5 mm | 429 mm |
| Top Tube Length | 500 mm | 511 mm | 524 mm | 536 mm | 548 mm | 561 mm | 575 mm | 591 mm | 609 mm | 629 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74.25 ° | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 420 mm | 445 mm | 475 mm | 495 mm | 505 mm | 515 mm | 535 mm | 560 mm | 580 mm | 605 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° | 72.75 ° | 73 ° | 73.25 ° | 73.5 ° |
| Head Tube Length | 120 mm | 133 mm | 140 mm | 147 mm | 163 mm | 180 mm | 193 mm | 210 mm | 228 mm | 245 mm |
| Chainstay Length | 412 mm | 412 mm | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm | 422 mm | 422 mm | 428 mm |
| Wheelbase | 971 mm | 992 mm | 992 mm | 992 mm | 1002 mm | 1008 mm | 1019 mm | 1034 mm | 1046 mm | 1066 mm |
| Bottom Bracket Drop | 59 mm | 59 mm | 73 mm | 73 mm | 73 mm | 73 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 701 mm | 723 mm | 761 mm | 778 mm | 796 mm | 814 mm | 832 mm | 850 mm | 832 mm | 868 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
REVEAL AL 105 belongs to the Rose Reveal model. Rose launched 59 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Rose REVEAL AL 105 2023 has a starting price of 1963$. Rose REVEAL SIX DISC Red eTap AXS 2023 on the other hand is the most expensive at 7962$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 1963$. Comparing this to the average Endurance bike price, we see that the price is 19.51% lower.
REVEAL AL 105 components
Fork material
REVEAL AL 105 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Rose REVEAL AL 105 2023, has a aluminum model. These wheels are less popular than 650b and 700c. However, they are a little lighter than 700c wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The REVEAL AL 105 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
