Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Frame weight starting at 1020g Matt Carbon/Shiny Red 50cm
Suspension Fork
Fork weight starting at 380g matt black
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000GS, 11-speed, black
Front Derailleur
Shimano 105 FD-R7000-F, braze-on, black
Cassette
Shimano 105 CS-R7000, 11-34
Crank
Shimano 105 FC-R7000, 50/34, black 170mm
Chain
Shimano CN-HG601, 118 links
Wheels
Rims
ROSE R25 Disc, 622x19C, TLR, 12/12, 29"
Tires
Continental Grand Prix 5000 foldable black/black 700x28C
Brakes
Brakes
Shimano 105 ST-R7025/BR-R7070, 160mm, black
Cockpit
Stem
Rose Square (6°), aluminium 6061, integrated cable guides, anodized black 90mm
Handlebar
Ritchey Road Comp Streem II (Rose Branding), Reach 73mm/Drop 28mm, black/matt 40cm
Seat
Saddle
Rose Edition by Selle Italia black
Seatpost
Rose D-Shape, for Reveal/Backroad, carbon, 8 mm offset, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 55cm | 57cm | 59cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.49 mm | 1.5 mm | 1.53 mm | 1.56 mm | 1.56 mm |
| Front Center | 578 mm | 585 mm | 590 mm | 595 mm | 604 mm | 620 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 63 mm | 61 mm | 59 mm | 56 mm | 57 mm | 56 mm |
| Stack | 535 mm | 557 mm | 571 mm | 588 mm | 604 mm | 621 mm |
| Reach | 367 mm | 374 mm | 380 mm | 384 mm | 388 mm | 399 mm |
| Top Tube Length | 511 mm | 529 mm | 541 mm | 553 mm | 567 mm | 589 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.25 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 475 mm | 495 mm | 515 mm | 537 mm | 566 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 142 mm | 154 mm | 170 mm | 190 mm | 208 mm |
| Chainstay Length | 409 mm | 409 mm | 411 mm | 411 mm | 414 mm | 416 mm |
| Wheelbase | 975 mm | 983 mm | 990 mm | 994 mm | 1007 mm | 1026 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
REVEAL FOUR DISC 105 completes the Rose Reveal model. There are 59 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
The most economical model, the Rose REVEAL FOUR DISC 105 2022 has a starting price of 3184$. Rose REVEAL SIX DISC Red eTap AXS 2022 on the other hand is the most expensive at 8599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Rose released this model in 2022, its price was 3184$. Doing a quick comparison, we notice that REVEAL FOUR DISC 105 price is 35.72% higher than the average cost of an Endurance bike.
REVEAL FOUR DISC 105 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Rose REVEAL FOUR DISC 105 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The REVEAL FOUR DISC 105 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
