rossignol Mandate Shift Deore 11 2022
2022 E-bike
Estimate price |
4,399$
Weight | 24.04 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 145mm -
Fork RockShox 35 Gold RL
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery Shimano STEPS E8035-L, (504Wh) -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Trail Electric 145mm travel | 6061 Alloy
Suspension Fork
Rockshox 35 Gold Rl Crown Adjust 29" Boost 15x110 Mxl Stealth Debonair 150, Gloss Black 44 Offset
Rear Shock
Rockshox Deluxe Select+ RT 185x52.5 Debonair 1 Token Mm Tune 320lb Threshold Trunnion Standard B 8x25mm Lower Mount
Drivetrain
Rear Derailleur
Shimano Deore M5100 11s
Shift Levers
Shimano Deore M5100, ISPEC EV
Cassette
Shimano Deore M5100, 11-51T
Crank
Samox, Shimano MTB, 34T; S, M, L: 165mm / XL: 170mm
Chain
Shimano HG601
Chain Guide
GW flip E-guide
Pedals
MTB platform pedal
Wheels
Front Hub
Shimano M410-B| J-Bend, Center Lock, 32h, TA 15x110
Rear Hub
ShimanoM400-B | J-Bend, Center Lock, 32h, TA 12x148, 11-speed
Rims
WTB ST i30 TCS 2.0 30mm with Shimano hubs
Tires
Maxxis DHF, 29x2.6, EXO/TR
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano M4100, ISPEC EV
Cockpit
Stem
Rossignol MTB 35Ø; 35mm | for internal Di2 routing
Handlebar
Rossignol MTB Switch | Internal routing for di2 | 7075 Aluminum, 20mm rise, Sweep: 9° back, 3° up. S : 760; M-XL : 780mm
Grips
Rossignol lock on, diamond design with waffle grip
Headset
FSA; ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
WTB Silverado, medium, steel
Seatpost
KS EDGE I
Motor & Battery
Motor
Shimano STEPS MTB E7000
Battery
Shimano STEPS E8035-L, (504Wh)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 753 mm | 765 mm | 791 mm | 818 mm |
| Rake | 47 mm | 43 mm | 46 mm | 47 mm |
| Trail | 123 mm | 127 mm | 124 mm | 123 mm |
| Stack | 605 mm | 609 mm | 618 mm | 632 mm |
| Reach | 431 mm | 447 mm | 467 mm | 485 mm |
| Top Tube Length | 564 mm | 577 mm | 602 mm | 624 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 375 mm | 425 mm | 445 mm | 485 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1206 mm | 1220 mm | 1247 mm | 1273 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mandate Shift Deore 11 completes the Rossignol E Mandate model. Rossignol released 6 e-bikes variations of this model so far. Take a sneak peek at all Rossignol E Mandate e-bikes models from 2022, by clicking here.
Model range prices
Rossignol Mandate Shift Deore 11 2022 is the cheapest e-bike model and costs 4399$. Rossignol Mandate Shift XT 2022 is the most expensive one and costs 6399$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2022 and its price was 4399$. Comparing this to the average Trail e-bike price, we see that the price is 30.73% more expensive.
Trail e-bikes average weight
The average weight for Trail e-bikes is 23.7 kg (52.25 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 24.04 kg (53 lbs), Rossignol e-bike is slightly heavier than average. In short, the average Trail e-bike weight is 1.43% lower than this one.
Overview of components
Fork
The Mandate Shift Deore 11 comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rossignol Mandate Shift Deore 11 e-bike has the Rockshox Deluxe Select+ RT 185×52.5 Debonair model installed, and has a travel of 145mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the Mandate Shift Deore 11 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Mandate Shift Deore 11 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Rossignol Mandate Shift Deore 11 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Rossignol model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
