Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Factory Float 36
-
Groupset XT -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rossignol Trail 140mm travel | 6061 Alloy
Suspension Fork
2023 FOX 36 - 29" - Factory - 140mm - GRIP2 - Gloss Black - Neutral Logo - QR:15x110 - 1.5T - 44mm Rake
Rear Shock
2023 FOX FLOAT X - Factory - Kashima - EVOL - LSR, 2 Pos Lever, LSC - Metric Trunnion - 185/47.5 - Neutral Decal
Drivetrain
Rear Derailleur
Shimano Deore XT M8100, SGS
Shift Levers
Shimano Deore XT M8100, ISPEC EV
Cassette
Shimano Deore XT M8100, 10-51T
Crank
Shimano Deore XT M8100, 32T
Bottom Bracket
Shimano MT800
Chain
Shimano Deore XT M8100
Chain Guide
e*thirteen Vario
Pedals
MTB platform pedal
Wheels
Front Hub
Shimano Deore XT M8110 | Straight Pull, Center Lock, 28h, TA 15x110
Rear Hub
Shimano Deore XT M8110 |Straight Pull, Center Lock, 28h TA 12x148, Micro Spline
Rims
e*thirteen TRS Plus Trail with Shimano Deore XT hubs
Tires
Maxxis Minion DHF, 2.5, 3C, EXO+, TR
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano Deore XT M8100, ISPEC EV
Cockpit
Stem
e*thirteen Plus bikeTechSpecsStem | 7075 Aluminum
Handlebar
e*thirteen Plus bikeTechSpecsHandlebar | 7075 Aluminum, 20mm rise, Sweep: 9° back, 5° up
Grips
Rossignol lock on, diamond design with waffle grip
Headset
ZS (ZS44/28.6-ZS56/40) / (NO.57)
Seat
Saddle
WTB Silverado, medium, cromoly
Seatpost
KS LEV Integra
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.34 mm | 1.38 mm | 1.32 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 345 mm | 345 mm |
| Front Center | 731 mm | 741 mm | 758 mm | 789 mm |
| Rake | 54 mm | 43 mm | 44 mm | 43 mm |
| Trail | 99 mm | 111 mm | 119 mm | 120 mm |
| Stack | 582 mm | 587 mm | 617 mm | 627 mm |
| Reach | 427 mm | 437 mm | 447 mm | 474 mm |
| Top Tube Length | 567 mm | 577 mm | 595 mm | 624 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 380 mm | 390 mm | 430 mm | 460 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 422 mm | 422 mm | 427 mm | 427 mm |
| Wheelbase | 1162 mm | 1162 mm | 1187 mm | 1218 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 29 mm | 29 mm |
| Wheels | 27" | 27" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mandate XT is a Rossignol Mandate model. Rossignol launched 13 bikes of this model so far. You can easily view all of the Rossignol Mandate bikes models from 2023, here.
Model range prices
Rossignol Mandate UNO Balance Bike 2023 is the cheapest bike model and costs 139$. Rossignol Mandate XT 2023 is the most expensive one and costs 4699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 4699$. Comparing the average cost of a Trail bike to this one, you will see that Mandate XT price is 70.13% higher.
Mandate XT components
Fork
The Fox Factory Float 36 is included from the factory. It has a travel distance of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rossignol Mandate XT bike has the 2023 FOX FLOAT X – Factory model installed, and has a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When leaving the production line, the Mandate XT model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Rossignol Mandate XT has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Mandate XT comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Mandate XT. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
