Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Groupset XT, e*thirteen -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery IPU750 / 750 Wh / carbon / 3,5 kg / Quick Release / 4,5 A charger -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
full carbon, hand made
Suspension Fork
140 mm travel / 110x15 mm / 51 mm offset
Rear Shock
DT SWISS R535 ONE, 185T X 55 MM / LINEAIR / INCONTROL
Drivetrain
Rear Derailleur
SHIMANO XT 8100 12-Speed
Shift Levers
SHIMANO XT I-SPEC EV
Cassette
SHIMANO CS 7100 10-51T. 12-SPEED
Crank
E*THIRTEEN PLUS, 165 mm (S, M) / 170 mm (L, XL)
Wheels
Rims
DT SWISS HX1700 SPLINE1 (30), RATCHET EXP OS 30 / 110-15/148-12 TAS / CL
Tires
SCHWALBE NOBBY NIC EVO, SUPER GROUND TLE SPEEDGRIP 29x2.4
Brakes
Brakes
SHIMANO XT 8120 FIN PAD
Cockpit
Stem
ROTWILD S240, Ø35 MM / 50 MM / AL6061 / MONKEYLINK INTERFACE
Handlebar
ROTWILD B280 AL7075, Ø35 MM / 35 MM RISE / 740 MM (S, M) / 780 MM (L, XL)
Grips
ERGON GA30 SPORTIVE WING
Headset
ACROS RW750 1.5 HEADSET W/ BLOCKLOCK
Seat
Saddle
ERGON SM
Seatpost
EIGHTPINS H01, Ø34.9 mm / 25 mm OFFSET / 145 mm (S) / 160 mm (M) / 180 mm (L) / 200 mm (XL)
Motor & Battery
Motor
Brose Drive S Mag / Air Cooler / up to 90 Nm torque
Battery
IPU750 / 750 Wh / carbon / 3,5 kg / Quick Release / 4,5 A charger
Remote
BROSE DISPLAY ALLROUND, BROSE APP / USB SPACER READY
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.41 mm | 1.36 mm | 1.31 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 733 mm | 757 mm | 795 mm | 831 mm |
| Rake | 66 mm | 54 mm | 52 mm | 54 mm |
| Trail | 94 mm | 108 mm | 110 mm | 108 mm |
| Stack | 607 mm | 613 mm | 633 mm | 645 mm |
| Reach | 400 mm | 434 mm | 465 mm | 494 mm |
| Top Tube Length | 584 mm | 613 mm | 650 | 684 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 413 mm | 444 mm | 473 mm | 509 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 140 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1187 mm | 1211 mm | 1249 mm | 1285 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 746 mm | 746 mm | 746 mm | 746 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
R.C750 PRO belongs to the Rotwild E Rc750 model. Rotwild launched 9 e-bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Rotwild R.C750 (HT) CORE 2022 is the most affordable e-bike of this model and has a price of 6370$. On the other hand, Rotwild R.C750 ULTRA 2022, is the most expensive and costs 11148$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2022 for 9024$. In conclusion, this e-bike price is 168.17% more expensive than the price of the average Trail e-bike.
R.C750 PRO components
Wheels
When leaving the production line, the R.C750 PRO model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The R.C750 PRO comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
R.C750 PRO comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the R.C750 PRO. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
