Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" / 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Rhythm Float 36
-
Groupset XT, e*thirteen -
Suspension Full -
Motor Brose 90Nm mid-drive -
Battery Rotwild IPU750, removeable, semi-integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 36 Rhythm E-Bike+, 2-position lever, GRIP damper
Rear Shock
FOX FLOAT DPX2 Performance, 3-position lever, trunnion mount, EVOL LV air can
Drivetrain
Rear Derailleur
Shimano XT 8100, 12-speed
Front Derailleur
N/A
Shift Levers
Shimano XT, 12-speed
Cassette
Shimano CS 7100, 12-speed, 10-51 tooth
Crank
e*thirteen Plus, Length: 160mm (SM), 165mm (MD/LG), 170mm (XL)
Chain
Shimano HG 7100, 12-speed
Chain Guide
Rotwild SL750 upper guide
Pedals
N/A
Wheels
Front Hub
DT Swiss H1900 Spline 30 wheelset, 15x110mm Boost front, 12x148mm Boost rear
Rear Hub
DT Swiss H1900 Spline 30 wheelset, 15x110mm Boost front, 12x148mm Boost rear
Rims
DT Swiss H1900 Spline 30 wheelset, 29" front, 27.5" rear
Spokes
DT Swiss H1900 Spline 30 wheelset
Tires
Continental Baron Projekt, 29" x 2.4" (front), 27.5" x 2.6" (rear)
Brakes
Brakes
Shimano 520, Shimano 203mm rotors (RT64 front, RT600 rear)
Brake Levers
Shimano 520
Cockpit
Stem
S35, 35mm clamp, 50mm length, MonkeyLink light mount ready
Handlebar
B35, 35mm clamp diameter, 15mm rise, 780mm width
Grips
Ergon GD10 Slim Factory, Frozen
Headset
Acros RW750 Block Lock
Seat
Saddle
Ergon SM-E Mountain Sport
Seatpost
Crankbrother Highline 20 dropper, Drop: 125mm (SM), 150mm (MD/LG/XL)
Motor & Battery
Motor
Brose Drive S Mag, air cooler skid plate, 90Nm
Battery
Rotwild IPU750, removeable, semi-integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.42 mm | 1.36 mm | 1.3 mm |
| Front Center | 727 mm | 753 mm | 791 mm | 825 mm |
| Rake | 52 mm | 44 mm | 42 mm | 40 mm |
| Trail | 110 mm | 119 mm | 121 mm | 123 mm |
| Stack | 606 mm | 613 mm | 633 mm | 644 mm |
| Reach | 401 mm | 433 mm | 464 mm | 496 mm |
| Top Tube Length | 584 mm | 613 mm | 650 | 684 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 413 mm | 444 mm | 473 mm | 509 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 140 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1168 mm | 1194 mm | 1232 mm | 1266 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 746 mm | 746 mm | 746 mm | 746 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
R.X750 Core completes the Rotwild E Rx750 model. Rotwild launched 10 e-bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
R.X750 Core components
Fork
The Fox Rhythm Float 36 is included from the factory. It has a travel distance of 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The R.X750 Core has a rear shock with a travel of 150mm. The model FOX FLOAT DPX2 Performance is the one installed in this e-bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the R.X750 Core model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The R.X750 Core comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
R.X750 Core comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Rotwild R.X750 Core includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
