Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Fork Suntour -
Groupset Tourney -
Suspension Hardtail -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
28", Alloy 6061
Suspension Fork
SR SUNTOUR 3010, Coil, 50 mm
Drivetrain
Rear Derailleur
Shimano Tourney, RD-TY300, 7-S
Shift Levers
Shimano Tourney, ST-EF41, EZ Fire Plus
Cassette
Shimano MF-TZ500, 14-34 T
Crank
Shimano Tourney, FC-TY301, Alloy
Chain
KMC HV500
Pedals
R Raymon, plastic
Wheels
Rims
Shimano MF-TZ500, 14-34 T
Tires
Impac StreetPac, Reflex, 42-622, 28x1.6
Brakes
Brakes
V-Brake, V-brake
Cockpit
Stem
R Raymon 25.4, adjustable
Handlebar
R Raymon Riser 25.4 mm, 640 mm, Sweep: 15 °, Rise: 16 mm
Grips
R Raymon Ergo
Seat
Seatpost
R Raymon, 27.2 mm, Patent
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.57 mm | 1.57 mm | 1.54 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 626 mm | 656 mm | 665 mm | 682 mm |
| Rake | 39 mm | 42 mm | 42 mm | 43 mm |
| Trail | 74 mm | 71 mm | 71 mm | 70 mm |
| Stack | 624 mm | 634 mm | 643 mm | 653 mm |
| Reach | 381 mm | 404 mm | 410 mm | 423 mm |
| Top Tube Length | 574 mm | 600 mm | 609 mm | 625 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 140 mm | 150 mm | 160 mm | 170 mm |
| Chainstay Length | 445 mm | 445 mm | 441 mm | 445 mm |
| Wheelbase | 1064 mm | 1094 mm | 1099 mm | 1120 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
TourRay 1.0 is a Rraymon Tourray model. 6 bikes variations carry this model name so far. You can easily view all of the Rraymon Tourray bikes models from 2021, here.
Model range prices
R RAYMON TourRay 1.0 2021 is the cheapest bike model and costs 721$. R RAYMON TourRay 6.0 2021 is the most expensive one and costs 1645$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Touring bikes average price
According to our math, the average price for a trustworthy Touring bike is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 721$. Doing a quick comparison, we notice that TourRay 1.0 price is 39.67% lower than the average cost of a Touring bike.
Overview of components
Fork
The TourRay 1.0 comes factory-installed with the Suntour fork. This has a travel range of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The TourRay 1.0 2021 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
TourRay 1.0 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
