Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 26" -
Travel Front 100mm -
Fork Manitou Mastodon Comp
-
Groupset NX, Race Face -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FAT Bike Titanium V4 3AL 2.5V
Suspension Fork
Manitou Mastodon EXT Comp 100mm
Drivetrain
Rear Derailleur
: SRAM NX Type 2 11spd
Shift Levers
: SRAM NX 11spd
Cassette
: SRAM PG-1130 11/42T 11spd
Crank
Race Face 175mm CINCH DM
Bottom Bracket
: Race Face 100mm BSA
Chain
: KMC 11SL
Wheels
Rims
Sun Ringle Mulefüt V2 Fat 26x80mm Front 15x150mm
Tires
Maxxis Minion FBF and FBR 4.8
Brakes
Brakes
: Avid Level T Hydraulic
Disk Rotors
Avid 180mm CenterLine
Cockpit
Stem
Race Face Turbine Basic 70mm
Handlebar
Race Face Turbine 35 760mm
Grips
Lizard Skin Northshore
Headset
Cane Creek ZS-44
Seat
Saddle
WTB Volt Comp
Seatpost
Race Face Ride or KS Dropper (S 125mm, M & L 150mm, XL 175mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.33 mm | 1.32 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 695 mm | 723 mm | 734 mm | 751 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 103 mm | 104 mm | 104 mm | 101 mm |
| Stack | 579 mm | 588 mm | 597 mm | 607 mm |
| Reach | 416 mm | 441 mm | 449 mm | 459 mm |
| Top Tube Length | 585 mm | 612 mm | 622 mm | 639 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 410 mm | 450 mm | 470 mm | 490 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1133 mm | 1161 mm | 1173 mm | 1190 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 698 mm | 725 mm | 741 mm | 758 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
MAYOR V4 Titanium 2 is part of the Rsd Mayor model. RSD released 29 bikes variations of this model so far. You can easily view all of the Rsd Mayor bikes models from 2020, here.
Model range prices
The most economical model, the RSD MAYOR V4 Aluminum 1 2020 has a starting price of 1499$. RSD MAYOR V4 Titanium 2 2020 on the other hand is the most expensive at 3899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fatbike bikes average price
According to our calculations, the average cost of a Fatbike bike that is reliable is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, RSD MAYOR V4 Titanium 2 price was 3899$. Comparing the average cost of a Fatbike bike to this one, you will see that MAYOR V4 Titanium 2 price is 123.69% higher.
Overview of components
Fork
The fork installed on this bike is the Manitou Mastodon Comp model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The MAYOR V4 Titanium 2 2020 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. RSD MAYOR V4 Titanium 2 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
RSD MAYOR V4 Titanium 2 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
