Santa Cruz 5010 S / Carbon C 2024
2024 Mountain
Estimate price |
5,799$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike Select+
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS High
142cm - 156cm
XS Low
142cm - 156cm
SM High
154cm - 166cm
SM Low
154cm - 166cm
MD High
164cm - 176cm
MD Low
164cm - 176cm
LG High
174cm - 186cm
LG Low
174cm - 186cm
XL High
184cm - 194cm
XL Low
184cm - 194cm
XXL High
192cm - 201cm
XXL Low
192cm - 201cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
5010 S / Carbon C
Suspension Fork
RockShox Pike Select+, 140mm
Rear Shock
RockShox Super Deluxe Select+, 210x50
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12spd
Shift Levers
SRAM GX Eagle, 12spd
Cassette
SRAM XG1275 Eagle, 12spd, 10-50t
Crank
SRAM GX Eagle 148 DUB 32t
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Chain
SRAM GX Eagle, 12spd
Wheels
Front Hub
DT Swiss 370, 15x110, Torque Cap, 6-Bolt, 28h
Rear Hub
DT Swis 370, 12x148, XD, 6-Bolt, 36t, 28h
Rims
Front: RaceFace AR Offeset 30, 29", Rear: RaceFace AR Offset 30, 27.5"
Tires
Front: Maxxis Minion DHR II 29"x2.4", 3C MaxxGrip, EXO, Rear: Maxxis Minion DHR II 27.5"x2.4", 3C MaxxTerra, EXO
Brakes
Brakes
SRAM G2 R
Cockpit
Stem
Burgtec Enduro MK3, 42mm
Handlebar
Burgtec RideWide Alloy
Grips
Santa Cruz Bicycles House Grips
Headset
Cane Creek 40 IS Integrated Headset
Seat
Saddle
WTB Silverado, CroMo
Seatpost
OneUp V2 Dropper Post, 31.6 -or- Reverb Stealth -or- Fox Transfer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | XS Low | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low | XXL High | XXL Low |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.48 mm | 1.4 mm | 1.41 mm | 1.35 mm | 1.37 mm | 1.31 mm | 1.33 mm | 1.3 mm | 1.31 mm | 1.26 mm | 1.27 mm |
| Bottom Bracket Height | 338 mm | 335 mm | 338 mm | 335 mm | 338 mm | 334 mm | 338 mm | 334 mm | 338 mm | 334 mm | 338 mm | 335 mm |
| Front Center | 719 mm | 718 mm | 748 mm | 748 mm | 779 mm | 779 mm | 803 mm | 803 mm | 832 mm | 832 mm | 863 mm | 863 mm |
| Rake | 45 mm | 45 mm | 46 mm | 45 mm | 46 mm | 45 mm | 45 mm | 45 mm | 46 mm | 45 mm | 45 mm | 46 mm |
| Trail | 123 mm | 126 mm | 122 mm | 126 mm | 122 mm | 126 mm | 123 mm | 126 mm | 122 mm | 126 mm | 124 mm | 125 mm |
| Stack | 603 mm | 605 mm | 612 mm | 614 mm | 626 mm | 628 mm | 635 mm | 637 mm | 653 mm | 655 mm | 666 mm | 668 mm |
| Reach | 414 mm | 410 mm | 438 mm | 435 mm | 463 mm | 460 mm | 483 mm | 480 mm | 503 mm | 500 mm | 528 mm | 525 mm |
| Top Tube Length | 548 mm | 548 mm | 574 mm | 575 mm | 602 mm | 603 mm | 628 mm | 629 mm | 649 mm | 650 | 677 mm | 678 mm |
| Seat Tube Angle | 77.4 ° | 77.1 ° | 77.4 ° | 77.1 ° | 77.4 ° | 77.1 ° | 77.1 ° | 76.8 ° | 77.3 ° | 77 ° | 77.3 ° | 77.1 ° |
| Seat Tube Length | 370 mm | 370 mm | 380 mm | 380 mm | 405 mm | 405 mm | 430 mm | 430 mm | 460 mm | 460 mm | 500 mm | 500 mm |
| Head Tube Angle | 65.2 ° | 64.9 ° | 65.2 ° | 64.9 ° | 65.2 ° | 64.9 ° | 65.2 ° | 64.9 ° | 65.2 ° | 64.9 ° | 65.1 ° | 64.9 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 115 mm | 115 mm | 125 mm | 125 mm | 145 mm | 145 mm | 160 mm | 160 mm |
| Chainstay Length | 432 mm | 433 mm | 434 mm | 435 mm | 437 mm | 438 mm | 440 mm | 441 mm | 443 mm | 444 mm | 446 mm | 447 mm |
| Wheelbase | 1151 mm | 1151 mm | 1182 mm | 1182 mm | 1216 mm | 1217 mm | 1243 mm | 1244 mm | 1275 mm | 1275 mm | 1309 mm | 1310 mm |
| Bottom Bracket Drop | 35 mm | 38 mm | 35 mm | 38 mm | 35 mm | 38 mm | 35 mm | 38 mm | 35 mm | 38 mm | 35 mm | 38 mm |
| Standover Height | 698 mm | 692 mm | 707 mm | 702 mm | 710 mm | 704 mm | 712 mm | 707 mm | 715 mm | 710 mm | 721 mm | 716 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 142 cm | 142 cm | 154 cm | 154 cm | 164 cm | 164 cm | 174 cm | 174 cm | 184 cm | 184 cm | 192 cm | 192 cm |
| Rider Max Height | 156 cm | 156 cm | 166 cm | 166 cm | 176 cm | 176 cm | 186 cm | 186 cm | 194 cm | 194 cm | 201 cm | 201 cm |
About this model
5010 S / Carbon C is part of the Santacruz 5010 model. 71 bikes variations carry this model name so far. Take a sneak peek at all Santacruz 5010 bikes models from 2024, by clicking here.
Model range prices
The most economical model, the Santa Cruz 5010 R / Carbon C 2024 has a starting price of 4799$. Santa Cruz 5010 X0 AXS RSV / Carbon CC 2024 on the other hand is the most expensive at 8999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Santa Cruz 5010 S / Carbon C price was 5799$. Comparing this to the average Trail bike price, we see that the price is 109.96% higher.
5010 S / Carbon C components
Fork
This bike has the RockShox Pike Select+ fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is RockShox Super Deluxe Select+, with a travel distance of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on 5010 S / Carbon C are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The 5010 S / Carbon C has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Santa Cruz 5010 S / Carbon C bike has 12 sizes, in the range of 142 cm – 201 cm (4.66 ft – 6.59 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Santa Cruz 5010 S / Carbon C comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
