Santa Cruz Bronson X01 / Carbon CC / 27.5 2019
2019 Mountain
Estimate price |
6,999$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 36
-
Groupset X01 Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bronson X01 / Carbon CC / 27.5
Suspension Fork
FOX 36 Float Performance Elite, 160mm 27.5"
Rear Shock
RockShox Super Deluxe RCT
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Shift Levers
SRAM X01 Eagle
Cassette
SRAM XG1295 Eagle 10-50T
Crank
SRAM X1 Eagle Carbon 148 DUB, 32t - 170mm (XS-S), 175mm (M-XL)
Chain
SRAM X01 Eagle 12 SPD
Wheels
Front Hub
DT 350 15x110 28H
Rear Hub
DT 350 148x12 28h XD
Rims
Race Face ARC Offset 30 27.5" Rims
Spokes
DT Competition Race (28)
Tires
Maxxis Minion DHF, 27.5"x2.6", 3C Terra EXO TR
Brakes
Brakes
SRAM Code RSC
Disk Rotors
Avid Centerline, 200mm Front, 180mm Rear
Cockpit
Stem
Race Face Aeffect R 50mm
Handlebar
SCB AM Carbon Bar 35x800
Grips
Santa Cruz Palmdale Grips
Headset
Cane Creek 40 IS Integrated Headset
Seat
Saddle
WTB Silverado Team Saddle
Seatpost
RockShox Reverb Stealth 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | XS Low | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.52 mm | 1.41 mm | 1.43 mm | 1.38 mm | 1.41 mm | 1.33 mm | 1.35 mm | 1.28 mm | 1.29 mm |
| Bottom Bracket Height | 344 mm | 340 mm | 344 mm | 340 mm | 344 mm | 340 mm | 344 mm | 340 mm | 344 mm | 340 mm |
| Front Center | 703 mm | 703 mm | 737 mm | 737 mm | 761 mm | 761 mm | 785 mm | 785 mm | 821 mm | 821 mm |
| Rake | 48 mm | 49 mm | 47 mm | 48 mm | 49 mm | 53 mm | 46 mm | 47 mm | 47 mm | 48 mm |
| Trail | 110 mm | 111 mm | 111 mm | 112 mm | 109 mm | 107 mm | 112 mm | 113 mm | 111 mm | 112 mm |
| Stack | 588 mm | 590 mm | 597 mm | 599 mm | 606 mm | 609 mm | 615 mm | 618 mm | 629 mm | 631 mm |
| Reach | 393 mm | 389 mm | 423 mm | 419 mm | 440 mm | 433 mm | 463 mm | 459 mm | 493 mm | 489 mm |
| Top Tube Length | 545 mm | 545 mm | 578 mm | 578 mm | 602 mm | 602 mm | 625 mm | 625 mm | 660 mm | 660 mm |
| Seat Tube Angle | 75.3 ° | 75 ° | 75.3 ° | 75 ° | 75.3 ° | 75 ° | 75.3 ° | 75 ° | 75.3 ° | 75 ° |
| Seat Tube Length | 370 mm | 370 mm | 380 mm | 380 mm | 405 mm | 405 mm | 430 mm | 430 mm | 460 mm | 460 mm |
| Head Tube Angle | 65.4 ° | 65.1 ° | 65.4 ° | 65.1 ° | 65.4 ° | 65.1 ° | 65.4 ° | 65.1 ° | 65.4 ° | 65.1 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 110 mm | 120 mm | 120 mm | 130 mm | 130 mm | 145 mm | 145 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1138 mm | 1138 mm | 1171 mm | 1171 mm | 1195 mm | 1195 mm | 1219 mm | 1219 mm | 1256 mm | 1256 mm |
| Bottom Bracket Drop | 10 mm | 14 mm | 10 mm | 14 mm | 10 mm | 14 mm | 10 mm | 14 mm | 10 mm | 14 mm |
| Standover Height | 698 mm | 696 mm | 708 mm | 704 mm | 725 mm | 721 mm | 725 mm | 719 mm | 724 mm | 719 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
Bronson X01 / Carbon CC / 27.5 belongs to the Santacruz Bronson model. 77 bikes variations carry this model name so far. You can easily view all of the Santacruz Bronson bikes models from 2019, here.
Model range prices
The most economical model, the Santa Cruz Bronson R Plus / Aluminum / 27.5 2019 has a starting price of 3499$. Santa Cruz Bronson XTR Reserve / Carbon CC / 27.5 2019 on the other hand is the most expensive at 9899$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Santa Cruz Bronson X01 / Carbon CC / 27.5 price was 6999$. In conclusion, this bike price is 94.47% higher than the price of the average Enduro bike.
Bronson X01 / Carbon CC / 27.5 components
Fork
Santa Cruz Bronson X01 / Carbon CC / 27.5 2019 bike is equipped with the Fox Performance Elite Float 36 fork, and has 160mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Santa Cruz Bronson X01 / Carbon CC / 27.5 bike has the RockShox Super Deluxe RCT model installed, and has a travel of 150mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Santa Cruz Bronson X01 / Carbon CC / 27.5 2019, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
The Santa Cruz model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
