Santa Cruz Chameleon R Plus / Aluminum / 27.5 2020
2020 Mountain
Estimate price |
2,399$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Fox Rhythm Float 34
-
Groupset NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 179cm
LG
176cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chameleon R Plus / Aluminum / 27.5
Suspension Fork
FOX Rhythm 34, 29"
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM PG1230 11-50t
Crank
SRAM NX Eagle 148 DUB, 30t - 170mm (S), 175mm (M-XL)
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Chain
SRAM NX Eagle
Wheels
Front Hub
SRAM MTH 716, 15x110, 32h
Rear Hub
SRAM MTH 746, 12x148, 32h
Rims
WTB ST i40 TCS 2.0 27.5 Rims
Spokes
DT Competition (32)
Tires
Front: Maxxis Rekon 27.5x2.8 EXO TR, Rear: Maxxis Rekon 27.5x2.8 EXO TR
Brakes
Brakes
SRAM Level T
Disk Rotors
Avid Centerline 180mm
Cockpit
Stem
Race Face Ride Stem
Handlebar
Race Face Ride
Grips
Santa Cruz Palmdale Grips
Headset
Cane Creek 10 IS Integrated Headset
Seat
Saddle
WTB Silverado Race Saddle
Seatpost
Race Face Aeffect, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.41 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 704 mm | 731 mm | 755 mm | 789 mm |
| Rake | 51 mm | 51 mm | 51 mm | 50 mm |
| Trail | 94 mm | 94 mm | 94 mm | 95 mm |
| Stack | 621 mm | 625 mm | 635 mm | 644 mm |
| Reach | 418 mm | 443 mm | 463 mm | 493 mm |
| Top Tube Length | 603 mm | 630 mm | 653 mm | 691 mm |
| Seat Tube Angle | 72.7 ° | 72.7 ° | 72.7 ° | 72.7 ° |
| Seat Tube Length | 390 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 67.2 ° | 67.2 ° | 67.2 ° | 67.2 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1124 mm | 1151 mm | 1175 mm | 1208 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 700 | 716 mm | 738 mm | 753 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 164 cm | 176 cm | 184 cm |
| Rider Max Height | 167 cm | 179 cm | 187 cm | 198 cm |
Model Overview
Chameleon R Plus / Aluminum / 27.5 is part of the Santacruz Chameleon model. 57 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Santa Cruz Chameleon D Plus / Aluminum / 27.5 2020 is the most economical model, with a starting price of 1799$. Santa Cruz Chameleon SE / Carbon C / 29 2020 on the other hand costs 4799$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2020 and its price was 2399$. Doing a quick comparison, we notice that Chameleon R Plus / Aluminum / 27.5 price is 15.13% lower than the average cost of a Trail bike.
Chameleon R Plus / Aluminum / 27.5 components
Fork
The fork installed on this bike is the Fox Rhythm Float 34 model. The travel on this model is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Chameleon R Plus / Aluminum / 27.5 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Santa Cruz Chameleon R Plus / Aluminum / 27.5 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Santa Cruz Chameleon R Plus / Aluminum / 27.5 bike has 4 sizes, in the range of 152 cm – 198 cm (4.99 ft – 6.5 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Santa Cruz model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
