Santa Cruz CHAMELEON S 29 / Aluminum 2023
2023 Mountain
Estimate price |
3,749$
Weight | 12.99 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 166cm
MD
164cm - 179cm
LG
177cm - 186cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CHAMELEON S 29 / Aluminum
Suspension Fork
FOX 34 Float Performance, 130mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12spd
Shift Levers
SRAM GX Eagle, 12spd
Cassette
SRAM XG1275 Eagle, 12spd, 10-50t
Crank
SRAM GX Eagle 148 DUB, 30t
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Chain
SRAM GX Eagle, 12spd
Wheels
Front Hub
DT Swiss 370, 15x110, 28h
Rear Hub
DT Swiss 370, 12x148, XD, 36t, 28h
Rims
Front: RaceFace AR Offset 30 29", Rear: RaceFace AR Offset 30 29"
Tires
Front: Maxxis Minion DHF 29"x2.5"WT, 3C MaxxGrip, EXO, TR, Rear: Maxxis Aggressor 29"x2.5"WT, EXO, TR
Brakes
Brakes
SRAM G2 R
Cockpit
Stem
Burgtec Enduro MK3, 42mm
Handlebar
Burgtec RideWide Alloy Bar, 800mm
Grips
Santa Cruz Bicycles House Grips
Headset
Cane Creek 40 IS Integrated Headset
Seat
Saddle
WTB Silverado Medium CroMo
Seatpost
SDG Tellis Dropper, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.42 mm | 1.37 mm | 1.32 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 729.4 mm | 758.6 mm | 782.8 mm | 812.1 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 617.1 mm | 626.2 mm | 635.2 mm | 644.3 mm |
| Reach | 417 mm | 442 mm | 462 mm | 487 mm |
| Top Tube Length | 593.1 mm | 618.3 mm | 640.4 mm | 665.8 mm |
| Seat Tube Angle | 74.1 ° | 74.3 ° | 74.4 ° | 74.6 ° |
| Seat Tube Length | 380 mm | 405 mm | 430 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1151 mm | 1180 mm | 1204 mm | 1234 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 679 mm | 679 mm | 683 mm | 705 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 164 cm | 177 cm | 184 cm |
| Rider Max Height | 166 cm | 179 cm | 186 cm | 198 cm |
Model Overview
CHAMELEON S 29 / Aluminum is part of the Santacruz Chameleon model. There are 57 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Santa Cruz CHAMELEON D MX / Aluminum 2023 has a starting price of 2599$. Santa Cruz CHAMELEON S 29 / Aluminum 2023 on the other hand is the most expensive at 3749$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 3749$. If we compare this with the average Trail bike cost we notice that the price is 35.73% higher.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 12.99 kg (28.64 lbs), the CHAMELEON S 29 / Aluminum model is slightly heavier than average. To sum up, it’s 0.08% heavier than the average weight of Trail bikes.
CHAMELEON S 29 / Aluminum components
Fork
Santa Cruz CHAMELEON S 29 / Aluminum 2023 bike is equipped with the Fox Performance Float 34 fork, and has 130mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
As for the wheels, Santa Cruz CHAMELEON S 29 / Aluminum 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Santa Cruz CHAMELEON S 29 / Aluminum is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 198 cm (4.99 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Santa Cruz CHAMELEON S 29 / Aluminum comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
