Santa Cruz Highball R / Carbon C / 29 2020
2020 Mountain
Estimate price |
2,899$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Rhythm Float 32
-
Groupset NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Highball R / Carbon C / 29
Suspension Fork
FOX Rhythm 32, 100mm, 29", w/Remote
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM PG1230 11-50t
Crank
SRAM NX Eagle 148 DUB, 34t - 170mm (S), 175mm (M-XL)
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Chain
SRAM NX Eagle
Wheels
Front Hub
SRAM MTH 716, 15x110, 32h
Rear Hub
SRAM MTH 746, 12x148, 32h
Rims
WTB ST i23 TCS 2.0 29" Rims
Spokes
DT Competition (32)
Tires
Front: Maxxis Aspen, 29"x2.25", EXO TR, Rear: Maxxis Aspen, 29"x2.25", EXO TR
Brakes
Brakes
SRAM Level T
Disk Rotors
Avid Centerline 160mm
Cockpit
Stem
Race Face Aeffect
Handlebar
Race Face Aeffect
Grips
ESI Chunky
Headset
Cane Creek 10 IS Integrated Headset
Seat
Saddle
WTB Silverado Race Saddle
Seatpost
Race Face Ride
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 662 mm | 690 mm | 714 mm | 751 mm |
| Rake | 55 mm | 54 mm | 55 mm | 55 mm |
| Trail | 81 mm | 82 mm | 81 mm | 81 mm |
| Stack | 601 mm | 611 mm | 620 mm | 639 mm |
| Reach | 410 mm | 435 mm | 455 mm | 485 mm |
| Top Tube Length | 592 mm | 620 mm | 643 mm | 679 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 430 mm | 470 mm | 530 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1093 mm | 1121 mm | 1145 mm | 1182 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 713 mm | 720 mm | 745 mm | 761 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Highball R / Carbon C / 29 belongs to the Santacruz Highball model. 49 bikes variations carry this model name so far. Take a sneak peek at all Santacruz Highball bikes models from 2020, by clicking here.
Model range prices
Santa Cruz Highball R / Carbon C / 29 2020 is the most affordable bike of this model and has a price of 2899$. On the other hand, Santa Cruz Highball XX1 AXS Reserve / Carbon CC / 29 2020, is the most expensive and costs 8999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 2899$. Comparing this to the average Crosscountry bike price, we see that the price is 52.18% higher.
Highball R / Carbon C / 29 components
Fork
Santa Cruz Highball R / Carbon C / 29 2020 bike is equipped with the Fox Rhythm Float 32 fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Highball R / Carbon C / 29 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Highball R / Carbon C / 29 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
