Santa Cruz Nomad R / Carbon C / 27.5 2022
2022 Mountain
Estimate price |
5,149$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 170mm -
Fork RockShox ZEB
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
155cm - 166cm
SM Low
155cm - 166cm
MD High
164cm - 176cm
MD Low
164cm - 176cm
LG High
174cm - 186cm
LG Low
174cm - 186cm
XL High
184cm - 196cm
XL Low
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Nomad R / Carbon C / 27.5
Suspension Fork
RockShox Zeb, 170mm, 27.5"
Rear Shock
RockShox Super Deluxe Select
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12spd
Shift Levers
SRAM NX Eagle
Cassette
SRAM PG1230 11-50t
Crank
SRAM Descendant Eagle DUB 32t
Bottom Bracket
SRAM DUB 68/73mm Threaded BB
Chain
SRAM NX Eagle
Chain Guide
E13 TRS Race SL ISCG05
Wheels
Front Hub
SRAM MTH 716, 15x110, Torque Cap, 32h
Rear Hub
SRAM MTH 746, 12x148, 32h
Rims
RaceFace AR Offset 30 27.5" Rims
Spokes
Sapim Race
Tires
Front: Maxxis Assegai 27.5"x2.5", 3C, Maxx-GRIP, EXO+, TR, Rear: Maxxis Minion DHR II 27.5"x2.4", 3C, EXO+
Brakes
Brakes
SRAM Guide RE
Disk Rotors
Avid Centerline 200mm
Cockpit
Stem
E13 Base
Handlebar
E13 TRS Base
Grips
Santa Cruz House Grips or Burgtec Bartender Pro Grip Minnaar
Headset
Cane Creek 10 IS Integrated Headset
Seat
Saddle
WTB Silverado Race Saddle or WTB Volt
Seatpost
SDG Tellis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.37 mm | 1.38 mm | 1.31 mm | 1.33 mm | 1.29 mm | 1.31 mm |
| Bottom Bracket Height | 344 mm | 340 mm | 344 mm | 340 mm | 344 mm | 340 mm | 344 mm | 340 mm |
| Front Center | 760 mm | 760 mm | 792 mm | 792 mm | 821 mm | 821 mm | 857 mm | 857 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 127 mm | 129 mm | 127 mm | 129 mm | 127 mm | 129 mm | 127 mm | 129 mm |
| Stack | 598 mm | 600 mm | 611.5 mm | 614 mm | 620.4 mm | 623 mm | 642.9 mm | 645 mm |
| Reach | 422 mm | 419 mm | 447 mm | 444 mm | 472 mm | 469 mm | 497 mm | 494 mm |
| Top Tube Length | 548 mm | 549 mm | 578 mm | 579 mm | 606 mm | 607 mm | 640 mm | 641 mm |
| Seat Tube Angle | 78.2 ° | 77.9 ° | 78 ° | 77.7 ° | 77.9 ° | 77.5 ° | 77.6 ° | 77.2 ° |
| Seat Tube Length | 380 mm | 380 mm | 405 mm | 405 mm | 430 mm | 430 mm | 460 mm | 460 mm |
| Head Tube Angle | 64 ° | 63.7 ° | 64 ° | 63.7 ° | 64 ° | 63.7 ° | 64 ° | 63.7 ° |
| Head Tube Length | 115 mm | 115 mm | 130 mm | 130 mm | 140 mm | 140 mm | 165 mm | 165 mm |
| Chainstay Length | 422 mm | 423 mm | 427 mm | 428 mm | 432 mm | 433 mm | 437 mm | 438 mm |
| Wheelbase | 1182 mm | 1183 mm | 1219 mm | 1220 mm | 1253 mm | 1254 mm | 1294 mm | 1295 mm |
| Bottom Bracket Drop | 10 mm | 14 mm | 10 mm | 14 mm | 10 mm | 14 mm | 10 mm | 14 mm |
| Standover Height | 707 mm | 703 mm | 729 mm | 724 mm | 730 mm | 725 mm | 729 mm | 724 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 155 cm | 155 cm | 164 cm | 164 cm | 174 cm | 174 cm | 184 cm | 184 cm |
| Rider Max Height | 166 cm | 166 cm | 176 cm | 176 cm | 186 cm | 186 cm | 196 cm | 196 cm |
About this model
Nomad R / Carbon C / 27.5 is a Santacruz Nomad model. There are 68 bikes that carry this model name. You can easily view all of the Santacruz Nomad bikes models from 2022, here.
Model range prices
Santa Cruz Nomad R / Carbon C / 27.5 2022 is the most economical model, with a starting price of 5149$. Santa Cruz Nomad X01 / Air / AXS / RSV / Carbon CC / 27.5 2022 on the other hand costs 10249$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Santa Cruz released this model in 2022, its price was 5149$. Comparing the average cost of an Enduro bike to this one, you will see that Nomad R / Carbon C / 27.5 price is 43.07% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox ZEB model. The travel on this model is 170mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is RockShox Super Deluxe Select, with a travel distance of 170mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on Nomad R / Carbon C / 27.5 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Nomad R / Carbon C / 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 155 cm – 196 cm (5.09 ft – 6.43 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Santa Cruz Nomad R / Carbon C / 27.5 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
