Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork Marzocchi Bomber Z1
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Marzocchi Bomber Z1, GRIP damper, Sweep Adjust, rebound adjust, 44mm offset
Rear Shock
FOX FLOAT DPX2 Performance, EVOL, 3-position lever, rebound adjust, 230mm x 65mm
Drivetrain
Rear Derailleur
Shimano SLX M7100, 12-speed, SHADOW RD+, SGS cage
Front Derailleur
None
Shift Levers
Shimano Deore M6100, 12-speed, RAPIDFIRE PLUS
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Crank
Shimano Deore M6130, 170mm length
Bottom Bracket
Shimano BB52, 73mm English/BSA threaded
Chain
KMC X12, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
KT, sealed bearings, DHF122 110x15mm Boost front, DHR2S5 157x12mm SuperBoost rear with MICRO SPLINE driver
Rear Hub
KT, sealed bearings, DHF122 110x15mm Boost front, DHR2S5 157x12mm SuperBoost rear with MICRO SPLINE driver
Rims
DT Swiss E532, 30mm internal width, 32 hole, tubeless ready
Spokes
Double-butted stainless steel
Tires
Front: Maxxis Minion DHR II, EXO, TR, 29" x 2.4", Rear: Maxxis Minion DHR II, EXO, TR, 27.5" x 2.3" (SM/MD) or 29" x 2.4" (LG/XL)
Brakes
Brakes
Shimano Deore M6100, 2-piston, 6-bolt rotors (203mm front, 180mm rear)
Brake Levers
Shimano Deore M6100
Cockpit
Stem
Race Face Chester, 40mm length, 0° rise, 35mm bar clamp
Handlebar
Race Face Chester, 780mm width, 35mm rise, 35mm clamp diameter
Grips
ODI Elite Motion
Headset
Prestine PT-F13, ZS44 upper, ZS56 lower
Seat
Saddle
Saracen Custom MTB, CrMo rails
Seatpost
KS Rage-i dropper, Westy remote lever, Drop: 125mm (SM), 150mm (MD/LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.3 mm | 1.26 mm | 1.23 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Stack | 612 mm | 617 mm | 630 mm | 644 mm |
| Reach | 449 mm | 474 mm | 499 mm | 524 mm |
| Top Tube Length | 597 mm | 618 mm | 646 mm | 674 mm |
| Seat Tube Angle | 76.4 ° | 76 ° | 75.7 ° | 75.4 ° |
| Seat Tube Length | 360 mm | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 64.6 ° | 64.6 ° | 64.6 ° | 64.6 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1214 mm | 1241 mm | 1272 mm | 1304 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm |
| Standover Height | 729 mm | 729 mm | 730 mm | 730 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ariel 60 belongs to the Saracen Ariel model. 11 bikes variations carry this model name so far. You can easily view all of the Saracen Ariel bikes models from 2021, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Enduro bikes average weight
On a deeper look, we notice that the average weight of an Enduro bike is 14.27 kg (31.46 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
considerably heavier than average, Ariel 60 has a weight of 16 kg (35.27 lbs). In other words, this model is 12.12% heavier than the average Enduro bike.
Overview of components
Fork
Saracen Ariel 60 2021 bike is equipped with the Marzocchi Bomber Z1 fork, and has 160mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Ariel 60 has a rear shock with a travel of 160mm. The model FOX FLOAT DPX2 Performance is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Ariel 60 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Saracen Ariel 60 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Ariel 60. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
