Saracen Mantra Elite LSL 2023
2023 Mountain
Estimate price |
2,573$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork Marzocchi Bomber Z2
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 172cm
MD
170cm - 180cm
LG
178cm - 186cm
XL
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SERIES 2 CUSTOM BUTTED AND HYDROFORMED 6061 ALLOY TUBESET. Headtube: ZS44-ZS56 tapered headtube. Technology: Chip-Slot dropout system / dropper post ready / Long Slack Low (LSL) geometry / UK developed. Axle: 12 x 148mm Boost.
Suspension Fork
MARZOCCHI BOMBER Z2. Travel: 140mm. Technology: Tapered steerer / rebound adjust / sweep adjust rail damper. Axle: 15x110 Boost.
Drivetrain
Rear Derailleur
SHIMANO XT M8100. Model: 12 speed.
Shift Levers
SHIMANO SLX M7100. Speed: 1x12 speed.
Cassette
SHIMANO DEORE M6100. Speed: 12 speed. Ratio: 10-51T.
Crank
SHIMANO SLX M7120. Model: 32T. Chain Ring: 170mm.
Bottom Bracket
SHIMANO BSA, 73MM.
Chain
KMC X12.
Wheels
Front Hub
SHIMANO SLX. Front: M7100. Rear: M7110-B. Brake Fitting: Center lock. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12x148. Hole: 32H.
Rear Hub
SHIMANO SLX. Front: M7100. Rear: M7110-B. Brake Fitting: Center lock. Front Axle Type: 15 x 110 Boost. Rear Axle Type: 12x148. Hole: 32H.
Rims
DT SWISS XM421. Hole: 32H. Size: 29" front 27.5" rear. Rim Width: 25mm internal. Tubeless Ready: Yes.
Spokes
DOUBLE-BUTTED STAINLESS STEEL.
Tires
MAXXIS MINION DHRII. Model: Exo TR. Size: 29 x 2.3 Front 27.5 x 2.3 Rear.
Brakes
Brakes
MAGURA MT5. Brake Type: Hydraulic four piston. Rotor Size: 180/180mm.
Brake Levers
MAGURA MT5.
Cockpit
Stem
RACEFACE AEFFECT. Length: 50mm. Rise: 6 degree. Clamp: 35mm clamp. Type: Ahead.
Handlebar
RACEFACE CHESTER. Width: 780mm. Rise: 35mm. Bend: 6 degree. Bar Bore: 35mm.
Grips
ODI ELITE MOTION.
Headset
PRESTINE PT-F13.
Seat
Saddle
SARACEN CUSTOM CRMO MTB.
Seatpost
KS RAGE I. Routing: Internal. Size: 30.9mm. Length: 392mm. Travel: 150mm (125mm on size small). Lever: Southpaw remote.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.32 mm | 1.29 mm |
| Front Center | 765 mm | 794 mm | 824 mm | 848 mm |
| Rake | 35 mm | 34 mm | 35 mm | 34 mm |
| Trail | 144 mm | 145 mm | 144 mm | 145 mm |
| Stack | 623 mm | 632 mm | 641 mm | 650 |
| Reach | 434 mm | 459 mm | 484 mm | 504 mm |
| Top Tube Length | 603 mm | 631 mm | 658 mm | 681 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 360 mm | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1195 mm | 1224 mm | 1254 mm | 1278 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 170 cm | 178 cm | 184 cm |
| Rider Max Height | 172 cm | 180 cm | 186 cm | 196 cm |
About this model
Mantra Elite LSL belongs to the Saracen Mantra model. There are 7 bikes that carry this model name. You can easily view all of the Saracen Mantra bikes models from 2023, here.
Model range prices
Saracen Mantra Trail LSL 2023 is the cheapest bike model and costs 1826$. Saracen Mantra Race LSL 2023 is the most expensive one and costs 3409$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2313$. Comparing the average cost of a Trail bike to this one, you will see that Mantra Elite LSL price is 19.41% smaller.
Overview of components
Fork
Saracen Mantra Elite LSL 2023 bike is equipped with the Marzocchi Bomber Z2 fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Saracen Mantra Elite LSL 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Saracen Mantra Elite LSL has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 196 cm (5.05 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Mantra Elite LSL. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
