Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL, SoloAir, rebound adjustment, 15mm x 110mm Boost axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM NX Eagle PG-1210, 11-50 tooth, 12-speed
Crank
SRAM SX Eagle, Boost, 170mm on S/M, 175mm on L/XL
Bottom Bracket
SRAM DUB, BSA 73mm
Chain
SRAM SX Eagle, 12-speed
Chain Guide
None
Pedals
Alloy MTB
Wheels
Front Hub
Front: Formula DC-711, 6-bolt, Boost 15mm x 110mm, Rear: Formula DCL-348S, 6-bolt, 12mm x 148mm
Rear Hub
Front: Formula DC-711, 6-bolt, Boost 15mm x 110mm, Rear: Formula DCL-348S, 6-bolt, 12mm x 148mm
Rims
Jalco MHL32OS, 27.5", 32 hole
Spokes
Double butted stainless steel
Tires
Vee Rubber Flow Snap, 29" x 2.6", Tackee compound, tubeless ready
Brakes
Brakes
Shimano BR-MT400, 180mm rotors
Brake Levers
Shimano BL-MT400
Cockpit
Stem
Saracen 6061 Die Cast Alloy, 40mm
Handlebar
Saracen OS 6061 DB Alloy, 6° bend, 12mm rise, 780mm width, 31.8mm diameter
Grips
Saracen Lock-On
Headset
FSA
Seat
Saddle
Saracen Custom
Seatpost
Saracen Alloy, micro-adjust, 350mm on S/M, 400mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.31 mm | 1.28 mm | 1.25 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 743 mm | 768 mm | 801 mm | 825 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 603 mm | 603 mm | 621 mm | 630 mm |
| Reach | 434 mm | 459 mm | 484 mm | 504 mm |
| Top Tube Length | 597 mm | 622 mm | 652 mm | 674 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 360 mm | 410 mm | 460 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 105 mm | 125 mm | 135 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1172 mm | 1197 mm | 1230 mm | 1254 mm |
| Bottom Bracket Drop | 52 mm | 52 mm | 52 mm | 52 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Mantra Trail LSL completes the Saracen Mantra model. There are 4 bikes that carry this model name. You can easily view all of the Saracen Mantra bikes models from 2020, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Saracen Mantra Trail LSL 2020 bike is equipped with the RockShox Recon Silver RL fork, and has 140mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Mantra Trail LSL bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Mantra Trail LSL has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Mantra Trail LSL comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
