Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 203mm -
Travel Rear 200mm -
Fork X Fusion
-
Groupset Zee -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
X-Fusion RV1 Coil, Roughcut, high and low speed compression, rebound adjust, 20mm x 110mm
Rear Shock
X-Fusion Vektor Coil RC, compression, rebound, 241mm x 76mm, Coil: 350lbs (S, M), 400lbs (L)
Drivetrain
Rear Derailleur
Shimano Zee M640 Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano Zee M640 Rapidfire Plus, 10-speed
Cassette
Shimano Deore CS-HG500, 10-speed, 11-25 tooth
Crank
Saracen Custom, 165mm
Bottom Bracket
BSA threaded
Chain
Shimano HG54
Chain Guide
MRP G4 CS
Pedals
None included
Wheels
Front Hub
Front: Formula DHL-92, 6 bolt, 20mm thru axle, Rear: Novatec DH82SB-S4S, 6 bolt, 12mm Saracen Taper Lock axle
Rear Hub
Front: Formula DHL-92, 6 bolt, 20mm thru axle, Rear: Novatec DH82SB-S4S, 6 bolt, 12mm Saracen Taper Lock axle
Rims
Kore Torsion SL 27.5, 32 hole
Spokes
Double butted stainless steel
Tires
Maxxis Highroller II, 42A Super Tacky, 27.5 x 2.4"
Brakes
Brakes
Shimano MT501 hydraulic disc
Brake Levers
Shimano MT501
Cockpit
Stem
Kore Torsion V2 Direct Mount, 31.8mm, 0 degree rise, 50mm length
Handlebar
Kore Torsion riser, 5 degree up, 7 degree back, 20mm rise, 800mm width
Grips
Saracen Lock-on
Headset
Prestine PT-F13S
Seat
Saddle
Kore Connex
Seatpost
3D-forged alloy, micro-adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.433 mm | 1.368 mm | 1.37 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm |
| Front Center | 786 mm | 806 mm | 826 mm |
| Rake | 53 mm | 53 mm | 41 mm |
| Trail | 122 mm | 122 mm | 135 mm |
| Stack | 602 mm | 602 mm | 630 mm |
| Reach | 420 mm | 440 mm | 460 mm |
| Top Tube Length | 593 mm | 613 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 400 mm | 400 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1226 mm | 1246 mm | 1266 mm |
| Bottom Bracket Drop | 1 mm | 1 mm | 1 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Myst AL is part of the Saracen Myst model. There are 14 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, even if your budget is less than the average, you might still be able to get a top-quality Downhill bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The X Fusion is included from the factory. It has a travel distance of 203mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the X-Fusion Vektor Coil RC model, with a travel of 200mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Saracen Myst AL 2019, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Myst AL comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
