Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 203mm -
Travel Rear 200mm -
Fork RockShox BoXXer
-
Groupset Zee -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Boxxer RC 29, DebonAir, LSC, rebound adjust, 20mm x 110mm Maxle Stealth axle
Rear Shock
FOX VAN RC Performance, compression and rebound adjust, 241mm x 76mm, Spring rate: 350lbs on M, 400lbs on L
Drivetrain
Rear Derailleur
Shimano ZEE RD-M640, 10-speed
Front Derailleur
None
Shift Levers
Shimano ZEE SL-M640, 10-speed
Cassette
Shimano Deore CS-HG500, 10-speed, 11-25 tooth
Crank
Shimano ZEE FC-M645, 165mm
Bottom Bracket
Shimano BB52, BSA 83mm
Chain
Shimano HG54
Chain Guide
MRP G4 CS
Pedals
Alloy MTB
Wheels
Front Hub
Front: Formula DHL-92, centerlock, 20mm thru axle, Rear: KT M5HR, centerlock, 12mm Saracen Taper Lock axle
Rear Hub
Front: Formula DHL-92, centerlock, 20mm thru axle, Rear: KT M5HR, centerlock, 12mm Saracen Taper Lock axle
Rims
Race Face AR 29", 32 hole
Spokes
Double butted stainless steel
Tires
Maxxis Minion DHR II, 29" x 2.4", 3C MaxxGrip, DH, TR
Brakes
Brakes
Shimano ZEE BR-M640, 203mm rotors
Brake Levers
Shimano ZEE M640
Cockpit
Stem
Race Face Chester, direct mount, 50mm length
Handlebar
Race Face Atlas, 5° up, 8° back, 20mm rise, 820mm width, 35mm diameter
Grips
Saracen Lock-On
Headset
Saracen Custom, 0mm front center option
Seat
Saddle
Saracen Custom
Seatpost
Race Face Chester, 325mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.393 mm | 1.343 mm |
| Bottom Bracket Height | 351 mm | 351 mm |
| Front Center | 807 mm | 830 mm |
| Rake | 59 mm | 59 mm |
| Trail | 125 mm | 125 mm |
| Stack | 613 mm | 618 mm |
| Reach | 440 mm | 460 mm |
| Top Tube Length | 593 mm | 614 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 400 mm |
| Head Tube Angle | 63 ° | 63 ° |
| Head Tube Length | 90 mm | 95 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1251 mm | 1274 mm |
| Bottom Bracket Drop | 23 mm | 23 mm |
| Wheels | 29" | 29" |
About this model
Myst Pro 29 completes the Saracen Myst model. 14 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Downhill bikes
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
This bike has the RockShox BoXXer fork installed. The fork’s travel is 203mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Myst Pro 29 has a rear shock with a travel of 200mm. The model FOX VAN RC Performance is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Saracen Myst Pro 29 2020, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Myst Pro 29 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
