Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 203mm -
Travel Rear 200mm -
Fork Fox Factory Float 40
-
Groupset Saint -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 40 Float Factory, Kashima, FIT GRIP2, 4-way high and low speed compression, 20mm x 110mm DH
Rear Shock
FOX DHX2 Factory, Kashima, HSC, LSC, HSR, LSR, 241mm x 76mm, Coil: 350lbs (M), 400lbs (L)
Drivetrain
Rear Derailleur
Shimano Saint M820 Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano Saint M820 Rapidfire Plus, 10-speed
Cassette
Shimano Deore CS-HG500, 10-speed, 11-25 tooth
Crank
Shimano Saint FC-M825, 165mm
Bottom Bracket
Shimano SM-BB80
Chain
Shimano HG54
Chain Guide
Gamut P30S
Pedals
None included
Wheels
Front Hub
Front: Shimano Saint M820, Center Lock, 20mm thru axle, Rear: KT DHR215, Center Lock, 12mm Saracen Taper Lock axle
Rear Hub
Front: Shimano Saint M820, Center Lock, 20mm thru axle, Rear: KT DHR215, Center Lock, 12mm Saracen Taper Lock axle
Rims
DT Swiss FR560 27.5, 32 hole
Spokes
Double butted stainless steel
Tires
Maxxis Minion DHR II, 3C, EXO, TR, 27.5 x 2.4"
Brakes
Brakes
Shimano Saint BR-M820 hydraulic disc, 203mm rotors
Brake Levers
Shimano Saint M820
Cockpit
Stem
Kore Torsion V2 Direct Mount, 31.8mm, 0 degree rise, 50mm length
Handlebar
PRO Tharsis 9.8 7050 alloy riser, 5 degree up, 9 degree back, 20mm rise, 800mm width
Grips
Saracen Lock-on
Headset
Saracen Offset
Seat
Saddle
PRO Tharsis 9.8
Seatpost
PRO Tharsis 9.8
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.353 mm | 1.31 mm |
| Bottom Bracket Height | 354 mm | 354 mm |
| Front Center | 827 mm | 842 mm |
| Rake | 54 mm | 54 mm |
| Trail | 124 mm | 124 mm |
| Stack | 609 mm | 609 mm |
| Reach | 450 mm | 465 mm |
| Top Tube Length | 602 mm | 617 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 400 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° |
| Head Tube Length | 115 mm | 115 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1272 mm | 1287 mm |
| Bottom Bracket Drop | 1 mm | 1 mm |
| Wheels | 27" | 27" |
About this model
Myst Team 27.5 completes the Saracen Myst model. There are 14 bikes that carry this model name. You can easily view all of the Saracen Myst bikes models from 2019, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Downhill bikes average price
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, this doesn’t mean that if you spend less money on a Downhill bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The Myst Team 27.5 comes factory-installed with the Fox Factory Float 40 fork. This has a travel range of 203mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX DHX2 Factory model, with a travel of 200mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Myst Team 27.5 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Myst Team 27.5 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
