Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 203mm -
Travel Rear 200mm -
Fork Fox Factory Float 40
-
Groupset Saint -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 40 FLOAT Factory, Kashima, FIT GRIP2, 4-way high and low speed compression, 20mm x 110mm thru axle
Rear Shock
FOX DHX2 Factory, Kashima, HSC, LSC, HSR, LSR, 241mm x 76mm, Spring rate: 350lbs on M, 400lbs on L
Drivetrain
Rear Derailleur
Shimano Saint RD-M820-SS, SHADOW RD+, 10-speed
Front Derailleur
None
Shift Levers
Shimano Saint M820, RAPIDFIRE PLUS, 10-speed
Cassette
Shimano Deore CS-HG500, 10-speed, 11-25 tooth
Crank
Shimano Saint FC-M825, 165mm
Bottom Bracket
Shimano Saint SM-BB80, BSA 83mm
Chain
Shimano HG54
Chain Guide
Gamut P30S
Pedals
Alloy MTB
Wheels
Front Hub
Front: Shimano Saint M820, centerlock, 20mm thru axle, Rear: KT DHR215, centerlock, 12mm Saracen Taper Lock axle
Rear Hub
Front: Shimano Saint M820, centerlock, 20mm thru axle, Rear: KT DHR215, centerlock, 12mm Saracen Taper Lock axle
Rims
DT Swiss FR 560 27.5", 32 hole
Spokes
Double butted stainless steel
Tires
Maxxis Assegai WT, 27.5" x 2.5", 3C, EXO, TR, 60 TPI
Brakes
Brakes
Shimano Saint BR-M820, 203mm rotors
Brake Levers
Shimano Saint M820
Cockpit
Stem
PRO Tharsis 9.8 Direct Mount, 0° rise, 50mm length
Handlebar
PRO Tharsis 9.8, 5° up, 9° back, 20mm rise, 800mm width, 31.8mm diameter
Grips
Saracen Lock-On
Headset
Saracen Custom, 0mm and +/- 5mm adjustable front center options
Seat
Saddle
PRO Tharsis 9.8
Seatpost
PRO Tharsis 9.8, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.353 mm | 1.31 mm |
| Bottom Bracket Height | 354 mm | 354 mm |
| Front Center | 827 mm | 842 mm |
| Rake | 54 mm | 54 mm |
| Trail | 124 mm | 124 mm |
| Stack | 609 mm | 609 mm |
| Reach | 450 mm | 465 mm |
| Top Tube Length | 602 mm | 617 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 400 mm |
| Head Tube Angle | 62.5 ° | 62.5 ° |
| Head Tube Length | 115 mm | 115 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1272 mm | 1287 mm |
| Bottom Bracket Drop | 1 mm | 1 mm |
| Wheels | 27" | 27" |
Model Overview
Myst Team 27.5 is part of the Saracen Myst model. Saracen released 14 bikes variations of this model so far. You can easily view all of the Saracen Myst bikes models from 2020, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Downhill bikes
Our math shows that the average cost of a dependable Downhill bike is 3391$. However, you could also get a good Downhill bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Myst Team 27.5 components
Fork
This bike has the Fox Factory Float 40 fork installed. The fork’s travel is 203mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the FOX DHX2 Factory model, with a travel of 200mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the Myst Team 27.5 bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Saracen Myst Team 27.5 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
