schindelhauer Ludwig XIV 2023
2023 Urban
Estimate price |
4,467$
Weight | 11.3 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 162cm
SM
159cm - 172cm
MD
169cm - 181cm
LG
178cm - 190cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium (AL6061-T6), triple butted aero tubing, forged dropouts with slider belt tensioning system and Schindelhauer – belt port, integrated seat post clamp, internal cable routing, smooth welded
Suspension Fork
Aluminium fork (tapered), 15mm through-axle, for flat mount disc brakes
Drivetrain
Shift Levers
Rohloff - Speedhub 14-speed internal gear hub
Crank
Shimano - Alfine Hollowtech II
Bottom Bracket
BSA, Shimano - Alfine Hollowtech II
Pedals
Schindelhauer - Urban Pedal, aluminium, CNC machined
Wheels
Rims
Schindelhauer - high flange front hub, Rohloff - Speedhub 14-speed internal gear hub, Alexrims - CXD26 rims w/ eyelets, Sapim - Race spokes, 3-cross and 2-cross laced
Tires
Continental - GP Urban Classic 35-622
Brakes
Brakes
Shimano - Alfine S7000 disc brake (hydraulic), 160mm
Cockpit
Stem
Schindelhauer
Handlebar
Satori - Noirette, aluminium
Grips
Schindelhauer - ergo leather grips
Headset
Tange Seiki - integrated, tapered 1 1/8“-1,5“
Seat
Saddle
Brooks - B17
Seatpost
Schindelhauer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.362 mm | 1.39 mm | 1.426 mm | 1.407 mm | 1.389 mm |
| Stack | 538 mm | 552 mm | 566 mm | 581 mm | 600 mm |
| Reach | 395 mm | 397 mm | 397 mm | 413 mm | 432 mm |
| Top Tube Length | 540 mm | 550 mm | 560 mm | 580 mm | 610 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 130 mm | 145 mm | 160 mm | 175 mm | 195 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1008 mm | 1015 mm | 1020 mm | 1040 mm | 1065 mm |
| Standover Height | 790 mm | 809 mm | 831 mm | 852 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 169 cm | 178 cm | 187 cm |
| Rider Max Height | 162 cm | 172 cm | 181 cm | 190 cm | 198 cm |
About this model
Ludwig XIV completes the Schindelhauer Ludwig model. 6 bikes variations carry this model name so far. Take a sneak peek at all Schindelhauer Ludwig bikes models from 2023, by clicking here.
Model range prices
Schindelhauer Ludwig VIII/XI 2023 is the most affordable bike of this model and has a price of 2224$. On the other hand, Schindelhauer Ludwig XIV 2023, is the most expensive and costs 4136$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hipster bikes average price
Our math shows that the average cost of a dependable Hipster bike is 612$. However, you could also get a good Hipster bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 4136$. In conclusion, this bike price is 575.82% more expensive than the price of the average Hipster bike.
Hipster bikes average weight
Hipster bikes have an average weight of 10 kg (22.05 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 11.3 kg (24.91 lbs), Schindelhauer bike is considerably heavier than average. In short, the average Hipster bike weight is 13% lower than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Ludwig XIV components
Fork material
Ludwig XIV has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The wheels on Ludwig XIV are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Schindelhauer Ludwig XIV has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Schindelhauer Ludwig XIV bike has 5 sizes, in the range of 151 cm – 198 cm (4.95 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
