Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Shimano -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
N LITENED 3 aluminum 700c crossfit tuned geometry S.R.T. (Smooth Ride Technology) Elastomer 10 mm x 135 mm dropout replaceable hanger 1 1/8 in headtube master
Suspension Fork
Schwinn® Smooth Ride Technology endurance frame with elastomer technology and Schwinn® cromoly fork
Drivetrain
Rear Derailleur
Shimano RD-TY500
Front Derailleur
Shimano FD-TY500 31.8 mm clamp
Shift Levers
Shimano EF500 EZ-FIRE 21-speed
Crank
Shimano Tourney 48/38/28T
Bottom Bracket
VP cartridge square taper 68 mm
Chain
7-speed
Pedals
Schwinn sport nylon
Wheels
Front Hub
Schwinn sport disc aluminum 9 mm x 100 mm QR 32H 6-bolt
Rear Hub
Schwinn sport disc aluminum 10 mm x 135 mm QR 32H 6-bolt
Rims
Alex DC26 aluminum double wall 32H
Spokes
14G, stainless steel
Tires
Schwinn sport 700c x 35c wire bead
Brakes
Brakes
Alloy mechanical disc brakes
Cockpit
Stem
Schwinn aluminum threadless 10° rise 25.4 mm clamp
Seat
Saddle
Schwinn sport steel rails
Seatpost
Aluminum 350 mm 25 mm offset 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Front Center | 595 mm | 616 mm | 621 mm | 625 mm | 640 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 526 mm | 546 mm | 565 mm | 576 mm | 596 mm |
| Seat Tube Angle | 72.8 ° | 73.3 ° | 72.6 ° | 72.3 ° | 72 ° |
| Seat Tube Length | 430 mm | 450 mm | 480 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.6 ° | 70.6 ° | 71.3 ° | 71.3 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 205 mm | 235 mm |
| Chainstay Length | 426 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1012 mm | 1038 mm | 1044 mm | 1049 mm | 1064 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 65 mm | 61 mm | 61 mm |
| Standover Height | 741 mm | 746 mm | 769 mm | 800 mm | 847 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Vantage F3 is part of the Schwinn Vantage model. Schwinn launched 9 bikes of this model so far. You can easily view all of the Schwinn Vantage bikes models from 2020, here.
Model range prices
The most economical model, the Schwinn Vantage F3 2020 has a starting price of 539$. Schwinn Vantage RX1 2020 on the other hand is the most expensive at 1729$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2020 and its price was 539$. If we compare this with the average Fitness bike cost we notice that the price is 21.71% lower.
Overview of components
Fork material
Vantage F3 has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The Vantage F3 2020 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Vantage F3 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
