Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Groupset Tourney, Shimano -
Suspension Hardtail -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, 700c comfort tuned geometry, 10 mm x 135 mm dropout, replaceable hanger, 1 1/8 in headtube
Suspension Fork
Schwinn® comfort-tuned aluminum step-thru frame and Zoom® 50 mm travel suspension fork
Drivetrain
Rear Derailleur
Shimano Tourney RD-TY300
Front Derailleur
Shimano FD-TY500, 31.8 mm clamp
Shift Levers
Shimano REVOSHIFT twist, 21-speed
Crank
SR Suntour XCC, 48/38/28T
Bottom Bracket
VP, cartridge, square taper, 68 mm
Chain
KMC Z7
Pedals
Schwinn comfort, nylon / Kraton
Wheels
Front Hub
Schwinn sport, aluminum, 9 mm x 100 mm QR, 32H
Rear Hub
Schwinn sport, aluminum, 10 mm x 135 mm QR, 32H
Rims
Alex DC26, aluminum, double wall, 32H
Spokes
Stainless steel
Tires
Kenda Kourier, 700c x 38c, wire bead
Brakes
Brakes
Aluminum linear-pull brakes
Cockpit
Stem
Schwinn, aluminum, threadless, adjustable rise, 25.4 mm clamp
Handlebar
Schwinn, steel, 620 mm width, 50 mm rise, 25.4 mm clamp
Grips
Schwinn ergo, dual density
Headset
Threadless, ZS44, semi-cartridge bearings
Seat
Saddle
Schwinn Comfort sport, steel rails
Seatpost
Aluminum, 300 mm, 18 mm offset, suspension, 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.7 mm | 1.74 mm | 1.72 mm |
| Front Center | 616 mm | 626 mm | 640 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 79 mm | 79 mm | 79 mm |
| Stack | 628.7 mm | 647.6 mm | 657 mm |
| Reach | 369.1 mm | 372.1 mm | 382.9 mm |
| Top Tube Length | 561 mm | 576 mm | 596 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 350 mm | 400 mm | 470 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 150 mm | 170 mm | 180 mm |
| Chainstay Length | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1070 mm | 1080 mm | 1094 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 605 mm | 626 mm | 619 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Voyageur Step-Thru belongs to the Schwinn Voyageur model. Schwinn launched 6 bikes of this model so far. You can easily view all of the Schwinn Voyageur bikes models from 2020, here.
Model range prices
Schwinn Voyageur 2020 is the most affordable bike of this model and has a price of 499$. On the other hand, Schwinn Voyageur Step-Thru 2020, is the most expensive and costs 499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 499$. Doing a quick comparison, we notice that Voyageur Step-Thru price is 12.63% smaller than the average cost of a Hybrid bike.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
As for the wheels, Schwinn Voyageur Step-Thru 2020, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Voyageur Step-Thru has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Schwinn Voyageur Step-Thru bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
