Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 160mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCOR 4060 full carbon frame | Lower-Link Driven Instant Center Linkage | 140 / 160mm rear wheel travel | Fully guided internal cable routing | Stash box | Boost 148 | SRAM UDH | Lower ISCG 05 mount / chainguide
Suspension Fork
RockShox Lyrik Ultimate RC2 | 150mm travel | 44mm rake
Rear Shock
RockShox Super Deluxe Ultimate Suspension
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle Trigger
Cassette
SRAM GX Eagle (XG-1275) | 10-52T
Crank
SRAM GX Eagle Carbon Lunar | 170mm length | 32T chainring | DUB interface
Chain
SRAM GX Eagle
Wheels
Rims
DT Swiss XM 1700 Spline | 30mm internal width | Tubeless ready
Tires
Maxxis Assegai 29 x 2.5" 3C MaxxTerra EXO TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra EXO+ TR (R)
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Burgtec Enduro MK3 | 31.8mm bar bore | 35mm length | 0° angle
Handlebar
SCOR Carbon Bar | 31.8mm clamp | 800mm wide | 20mm rise | 5° upsweep | 7.5° backsweep
Grips
Burgtec Bartender Pro
Seat
Saddle
WTB Silverado Titanium Medium
Seatpost
Bikeyoke Divine | S 125mm | M / L 160mm | XL 185mm travel | Triggy Alpha lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.374 mm | 1.325 mm | 1.289 mm | 1.233 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 752 mm | 777 mm | 802 mm | 832 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 119 mm | 125 mm | 130 mm |
| Stack | 599 mm | 611 mm | 625 mm | 636 mm |
| Reach | 436 mm | 461 mm | 485 mm | 516 mm |
| Top Tube Length | 561 mm | 590 mm | 621 mm | 655 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 400 mm | 425 mm | 440 mm | 470 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 87 mm | 99 mm | 115 mm | 127 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1185 mm | 1210 mm | 1235 mm | 1265 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm | 29 mm |
| Standover Height | 714 mm | 723 mm | 731 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
Model Overview
4060 ST GX completes the Scor 4060 model. SCOR launched 18 bikes of this model so far. Take a sneak peek at all Scor 4060 bikes models from 2023, by clicking here.
Model range prices
SCOR 4060 ST NX 2023 is the most affordable bike of this model and has a price of 4899$. On the other hand, SCOR 4060 ST GX 2023, is the most expensive and costs 7199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When SCOR released this model in 2023, its price was 7199$. In conclusion, this bike price is 100.03% higher than the price of the average Enduro bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
SCOR 4060 ST GX 2023 bike is equipped with the RockShox Lyrik Ultimate fork, and has 150mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The 4060 ST GX has a rear shock with a travel of 160mm. The model RockShox Super Deluxe Ultimate Suspension is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the 4060 ST GX bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. SCOR 4060 ST GX is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the 4060 ST GX. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
