Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Darfon 36V 720Wh, Shimano Steps service included -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCOR 4060 Z full carbon frame, Lower-Link Driven Instant Center Linkage, 160mm rear wheel travel, Fully guided internal cable routing, Boost 148, SRAM Universal Derailleur Hanger, Lower ISCG 05 mount / Chainguide
Suspension Fork
Fox Float 38 Factory Series E-Bike, 170mm travel, Grip2 damper, Low & high speed compression adjust, Low & high speed rebound adjust, 44mm rake, E-MTB rated
Rear Shock
Fox Float X Factory Series, Compression adjust, Rebound adjust, 2 position adjust
Drivetrain
Rear Derailleur
Shimano Deore XT (RD-M8100), 12 speed
Shift Levers
Shimano Deore XT (SL-M8100-R)
Cassette
Shimano Deore XT (CS-M8100-12), 10-51T
Crank
Shimano Deore XT (FC-M8150), 165mm length, 34T chainring (SM-CRE80-12-B)
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano Deore XT (CN-M8100)
Wheels
Front Hub
DT Swiss 370, Ratchet LN freehub, Straightpull spoke interface, Boost Spacing
Rear Hub
DT Swiss 370, Ratchet LN freehub, Straightpull spoke interface, Boost Spacing
Rims
DT Swiss H 1900 Spline, 30mm internal width, Tubeless ready
Tires
Maxxis Assegai 29 x 2.5" (F) / Maxxis Dissector 29 x 2.4" (R), Compound: 3C Maxx Grip (F) / 3C Maxx Terra (R), Casing: EXO+ (F) / Double Down (R), Tubeless ready
Brakes
Brakes
Shimano Deore XT (BR-M8120), BL-M8100 levers, SM-RT86 rotors; 203mm
Cockpit
Stem
Burgtec Enduro MK3, 3D forged and fully CNC machined, 31.6mm bar bore, 35mm lenght, 0° angle
Handlebar
SCOR Carbon Bar, 31.8mm clamp, 800mm wide, 20mm rise, 5° up sweep - 7.5° back sweep
Seat
Saddle
Fizik Terra Alpaca
Seatpost
Bikeyoke Divine, S 125mm, M/L 160mm, XL 185mm travel, Triggy Alpha lever
Motor & Battery
Motor
Shimano Steps EP8 (DU-EP800)
Battery
Darfon 36V 720Wh, Shimano Steps service included
Remote
Shimano Steps EP8 Wireless Cycle Computer (SC-EM800)
Charger
Darfon Smart Plus 100-240V 4A EU
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.382 mm | 1.333 mm | 1.291 mm | 1.237 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 773 mm | 798 mm | 823 mm | 853 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 131 mm | 136 mm | 144 mm | 150 mm |
| Stack | 601 mm | 612 mm | 626 mm | 637 mm |
| Reach | 435 mm | 459 mm | 485 mm | 515 mm |
| Top Tube Length | 562 mm | 590 mm | 621 mm | 655 mm |
| Seat Tube Angle | 77.9 ° | 77.9 ° | 77.9 ° | 77.9 ° |
| Seat Tube Length | 400 mm | 425 mm | 440 mm | 470 mm |
| Head Tube Angle | 63.8 ° | 63.8 ° | 63.8 ° | 63.8 ° |
| Head Tube Length | 87 mm | 99 mm | 115 mm | 127 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1206 mm | 1230 mm | 1255 mm | 1285 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 200 cm |
About this model
4060 Z LT XT is part of the Scor E 4060 model. SCOR launched 16 e-bikes of this model so far. You can easily view all of the Scor E 4060 e-bikes models from 2022, here.
Model range prices
SCOR 4060 Z LT SLX USA 2022 is the most economical model, with a starting price of 6599$. SCOR 4060 Z LT XT 2022 on the other hand costs 8812$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, SCOR 4060 Z LT XT price was 8812$. In conclusion, this e-bike price is 84.16% more expensive than the price of the average Enduro e-bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The 4060 Z LT XT comes factory-installed with the Fox Factory Float 38 fork. This has a travel range of 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
SCOR 4060 Z LT XT e-bike has the Fox Float X Factory Series model installed, and has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the 4060 Z LT XT e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. SCOR 4060 Z LT XT is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
4060 Z LT XT comes in 4 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the 4060 Z LT XT. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
