Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Addict CX HMF Disc / IMP Carbon technology / CX Race geometry / Replaceable Dropout
Suspension Fork
Addict HMF Disc 1 1/8" - 1 1/4" tapered Carbon steerer Alloy Dropout
Drivetrain
Rear Derailleur
Shimano 105 RD-5800-GS 22 Speed
Front Derailleur
Shimano 105 Black FD-5800
Shift Levers
Shimano ST-RS505 Disc Dual control 22 Speed
Cassette
Shimano 105 CS-5800 11-32 T
Crank
Shimano FC-RS500 Black Hyperdrive 36x46 T
Bottom Bracket
Shimano BB-RS500-PB
Chain
Shimano CN-HG600
Wheels
Front Hub
Syncros RP2.0 Disc
Rear Hub
Syncros RP2.0 Disc
Rims
Syncros RP2.0 Disc 28 Front / 28 Rear
Spokes
Syncros RP2.0 Disc
Tires
Continental Cyclocross xKing wire 700x35C
Brakes
Brakes
Shimano BR-RS505 Hyd Disc 160/F and 160/R mm SM-RT70 CL Rotor
Cockpit
Stem
Syncros FL2.0 1 1/8" / four Bolt 31.8mm
Handlebar
Syncros RR2.0 Anatomic 31.8mm
Headset
Integrated Cartridge
Seat
Saddle
Syncros FL2.0
Seatpost
Syncros Carbon RR1.2 27.2/350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.47 mm | 1.49 mm | 1.49 mm | 1.48 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 572 mm | 589 mm | 604 mm | 630 mm | 643 mm |
| Rake | 40 mm | 40 mm | 49 mm | 56 mm | 48 mm |
| Trail | 82 mm | 82 mm | 66 mm | 59 mm | 67 mm |
| Stack | 526.8 mm | 550.5 mm | 569.4 mm | 588.3 mm | 607.2 mm |
| Reach | 365 mm | 374 mm | 383 mm | 395 mm | 410 mm |
| Top Tube Length | 510 mm | 530 mm | 550 mm | 573 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 989 mm | 1007 mm | 1022 mm | 1048 mm | 1061 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 754 mm | 780 mm | 801 mm | 819 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Addict CX 20 Disc is a Scott Addict model. Scott released 134 bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Cyclocross bikes average price
According to our math, the average price for a trustworthy Cyclocross bike is 2012$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Cyclocross bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Cyclocross bikes average weight
If we make a quick analysis of the average weight of a Cyclocross bike, we get 8.79 kg (19.38 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 8.66 kg (19.09 lbs), the Addict CX 20 Disc model is slightly lighter than average. In conclusion, the average Cyclocross bike weighs 1.5% more than Addict CX 20 Disc.
Addict CX 20 Disc components
Fork material
Addict CX 20 Disc has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Scott Addict CX 20 Disc 2017, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Addict CX 20 Disc comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
