Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Addict Gravel Disc HMX / IMP Carbon technology Gravel Race geometry / Replaceable Dropout
Suspension Fork
Addict Gravel HMX Flatmount Disc 1 1/8" - 1 1/4" tapered Carbon steerer Alloy Dropout
Drivetrain
Rear Derailleur
SRAM Force 1 11 Speed long cage
Shift Levers
SRAM Force 1 Hydraulic Disc 11 Speed
Cassette
SRAM XG 1195 10-42
Crank
SRAM Force 1 44T
Bottom Bracket
SRAM PF86 GXP
Chain
SRAM PC 1170
Wheels
Front Hub
Syncros RT1.0 Disc
Rear Hub
Syncros RT1.0 Disc
Rims
Syncros RT1.0 Carbon Disc 24 Front / 24 Rear
Spokes
Syncros RT1.0 Disc
Tires
Schwalbe G-ONE FOLD 700x35C
Brakes
Brakes
SRAM Force 1 Hydraulic Disc 160/F and 160/R mm Centerline Rotor
Cockpit
Stem
Syncros RR1.5 1 1/8" / four Bolt 31.8mm
Handlebar
Syncros GR1.0 Carbon Gravel 31.8mm
Headset
Syncros Integrated
Seat
Saddle
Syncros FL1.0
Seatpost
Syncros Carbon FL1.0 27.2/350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.47 mm | 1.49 mm | 1.49 mm | 1.48 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 572 mm | 589 mm | 604 mm | 630 mm | 643 mm |
| Rake | 40 mm | 40 mm | 49 mm | 56 mm | 48 mm |
| Trail | 84 mm | 84 mm | 68 mm | 61 mm | 69 mm |
| Stack | 526.8 mm | 550.5 mm | 569.4 mm | 588.3 mm | 607.2 mm |
| Reach | 365 mm | 374 mm | 383 mm | 395 mm | 410 mm |
| Top Tube Length | 510 mm | 530 mm | 550 mm | 573 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 989 mm | 1007 mm | 1022 mm | 1048 mm | 1061 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 754 mm | 780 mm | 801 mm | 819 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Addict Gravel 10 Disc is part of the Scott Addict model. 134 bikes variations carry this model name so far. Take a sneak peek at all Scott Addict bikes models from 2017, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Gravel bikes
The average weight for Gravel bikes is 8.13 kg (17.92 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Scott Addict Gravel 10 Disc it’s weighing 7.54 kg (16.62 lbs). At this weight, is a bit lighter than average. In conclusion, the average Gravel bike weighs 7.82% more than Addict Gravel 10 Disc.
Addict Gravel 10 Disc components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Addict Gravel 10 Disc are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Addict Gravel 10 Disc has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
