Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Addict Gravel Disc HMF / IMP Carbon technology Gravel Race geometry / Replaceable Dropout
Suspension Fork
Addict Gravel HMF Flatmount Disc 1 1/8" - 1 1/4" tapered Carbon steerer Alloy Dropout
Drivetrain
Rear Derailleur
Shimano Ultegra RD-6800-GS 22 Speed
Front Derailleur
Shimano Ultegra FD-6800
Shift Levers
Shimano ST-RS685 Disc Dual control 22 Speed
Cassette
Shimano 105 CS-5800 11-32
Crank
Shimano Ultegra FC-6800 Hollowtech II 50x34 T
Bottom Bracket
Ultegra SM-BB72-41
Chain
Shimano 105 CN-HG601-11
Wheels
Front Hub
Syncros RP2.0 Disc
Rear Hub
Syncros RP2.0 Disc
Rims
Syncros RP2.0 Disc 28 Front / 28 Rear
Spokes
Syncros RP2.0
Tires
Schwalbe G-ONE FOLD 700x35C
Brakes
Brakes
Shimano BR-RS805 Hyd Disc 160/F and 160/Rmm SM-RT99 CL Rotor
Cockpit
Stem
Syncros RR1.5 1 1/8" / four Bolt 31.8mm
Handlebar
Syncros GR2.0Alloy Gravel 31.8mm
Headset
Syncros Integrated
Seat
Saddle
Syncros FL2.0
Seatpost
Syncros Carbon FL1.0 27.2/350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.47 mm | 1.49 mm | 1.49 mm | 1.48 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 572 mm | 589 mm | 604 mm | 630 mm | 643 mm |
| Rake | 40 mm | 40 mm | 49 mm | 56 mm | 48 mm |
| Trail | 84 mm | 84 mm | 68 mm | 61 mm | 69 mm |
| Stack | 526.8 mm | 550.5 mm | 569.4 mm | 588.3 mm | 607.2 mm |
| Reach | 365 mm | 374 mm | 383 mm | 395 mm | 410 mm |
| Top Tube Length | 510 mm | 530 mm | 550 mm | 573 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 95 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 989 mm | 1007 mm | 1022 mm | 1048 mm | 1061 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 754 mm | 780 mm | 801 mm | 819 mm | 837 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Addict Gravel 20 Disc belongs to the Scott Addict model. 134 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Gravel bikes
Gravel bikes weigh an average of 8.13 kg (17.92 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
a bit heavier than average, Addict Gravel 20 Disc has a weight of 8.64 kg (19.05 lbs). To sum up, it’s 6.27% heavier than the average weight of Gravel bikes.
Addict Gravel 20 Disc components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Addict Gravel 20 Disc are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Scott Addict Gravel 20 Disc bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
