Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork SunTour XCR 34
-
Groupset SX Eagle, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery PowerTube 625Wh -
Drivetrain 1 × 12 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy frame Tapered Headtube E2 Custom butted tubing / internal cable routing Bosch Gen4 / Integr. removable Battery / Boost 148x12mm DO Kickstand mount / Range Booster Ready
Suspension Fork
SR Suntour XCR34 Air 15x110mm QR axle / Tapered Steerer Remote Lockout / 120mm travel
Drivetrain
Rear Derailleur
SRAM SX Eagle / 12 Speed
Shift Levers
SRAM SX Eagle Single Click
Cassette
SRAM PG1210 / 11-50 T
Crank
FSA CK-745 / 165mm
Bottom Bracket
Bosch, press-fit
Chain
SRAM SX Eagle
Wheels
Front Hub
Formula CL-811 / 15x110mm
Rear Hub
Formula CL-148S / Boost 148x12mm
Rims
Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready
Spokes
Stainless Black
Tires
Kenda Booster 29x2.6" / 30TPI
Brakes
Brakes
Shimano BR-MT420 4 Piston
Disk Rotors
Front: SM-RT30 CL 180mm / Rear: RT-EM300 CL 180mm
Cockpit
Stem
Syncros FL2.0 / 6061 Alloy 6° / integrated Top Cap / 31.8mm / 1 1/8"
Handlebar
Syncros Hixon 2.0 / Alloy 6061D.B. 12mm rise / 9° / 740mm Syncros Comfort lock-on grips
Headset
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8" OD 50/62mm / ID 44/56mm
Seat
Saddle
Syncros ER2.0
Seatpost
Syncros 3.0 / 31.6mm
Motor & Battery
Motor
Bosch Performance CX
Battery
PowerTube 625Wh
Remote
Bosch Purion
Charger
2A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.601 mm | 1.552 mm | 1.508 mm | 1.473 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 686 mm | 706 mm | 728 mm | 748 mm |
| Rake | 42 mm | 42 mm | 42 mm | 41 mm |
| Trail | 90.5 mm | 97 mm | 97 mm | 97 mm |
| Stack | 637 mm | 644 mm | 653 mm | 663 mm |
| Reach | 398 mm | 415 mm | 433 mm | 450 mm |
| Top Tube Length | 580 mm | 600 mm | 620 mm | 640 mm |
| Seat Tube Angle | 75.2 ° | 75 ° | 74.9 ° | 74.7 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1160 mm | 1180 mm | 1202 mm | 1222 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | 57 mm |
| Standover Height | 787 mm | 809 mm | 838 mm | 853 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Aspect eRIDE 910 is part of the Scott E Aspect model. Scott launched 17 e-bikes of this model so far. You can easily view all of the Scott E Aspect e-bikes models from 2021, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Fitness e-bikes
According to our calculations, the average cost of a Fitness e-bike that is reliable is 2351$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Average weight for Fitness e-bikes
On a deeper look, we notice that the average weight of a Fitness e-bike is 22.85 kg (50.38 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 23 kg (50.71 lbs), Scott e-bike is slightly heavier than average. To sum up, it’s 0.66% heavier than the average weight of Fitness e-bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The SunTour XCR 34 is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Aspect eRIDE 910 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Aspect eRIDE 910 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Scott Aspect eRIDE 910 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
