Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CR1 Carbon / IMP Carbon technology / Road Comfort geometry / INT BB
Suspension Fork
CR1 Carbon 1 1/8" Carbon steerer Alloy Dropout
Drivetrain
Rear Derailleur
Shimano 105 Black RD-5800-GS 22 Speed
Front Derailleur
Shimano 105 Black FD-5800
Shift Levers
Shimano 105 Black ST-5800 Dual control 22 Speed
Cassette
Shimano 105 CS-5800 11 Speed 11-32 T
Crank
Shimano FC-RS500 Black Hyperdrive 50x34 T
Bottom Bracket
Shimano BB-RS500-PB
Chain
KMC X11
Wheels
Front Hub
Formula Team 24 H
Rear Hub
Formula Team 28 H
Rims
Syncros Race 22 24 Front / 28 Rear
Spokes
14G StainlessBlack 2mm
Tires
Continental Ultra Sport 700x23C
Brakes
Brakes
Shimano BR-R561 Black Super SLR Dual pivot
Cockpit
Stem
Syncros RR2.0 1 1/8" / four Bolt 31.8mm
Handlebar
Syncros RR2.0 Ergonomic 31.8mm
Headset
Syncros Int. Cartridge
Seat
Saddle
Syncros FL2.5
Seatpost
Syncros RR1.4 Carbon/AL 31.6/300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.38 mm | 1.44 mm | 1.47 mm | 1.51 mm | 1.53 mm | 1.51 mm |
| Bottom Bracket Height | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm |
| Front Center | 579 mm | 582 mm | 584 mm | 585 mm | 596 mm | 605 mm | 625 mm |
| Rake | 47 mm | 44 mm | 53 mm | 44 mm | 45 mm | 42 mm | 42 mm |
| Trail | 70 mm | 70 mm | 48 mm | 58 mm | 57 mm | 60 mm | 60 mm |
| Stack | 515 mm | 521 mm | 547 mm | 567 mm | 586 mm | 605 mm | 622 mm |
| Reach | 370 mm | 378 mm | 381 mm | 385 mm | 389 mm | 396 mm | 411 mm |
| Top Tube Length | 507 mm | 517 mm | 532 mm | 547 mm | 562 mm | 577 mm | 597 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.3 ° | 73.3 ° |
| Seat Tube Length | 470 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 111 mm | 116 mm | 136 mm | 156 mm | 176 mm | 196 mm | 216 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 977 mm | 980 mm | 982 mm | 983 mm | 994 mm | 1003 mm | 1023 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 725 mm | 739 mm | 767 mm | 786 mm | 805 mm | 825 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
About this model
CR1 20 completes the Scott Cr1 model. Scott released 3 bikes variations of this model so far. You can easily view all of the Scott Cr1 bikes models from 2017, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Endurance bikes
Endurance bikes weigh an average of 8.2 kg (18.08 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly heavier than average, CR1 20 has a weight of 8.46 kg (18.65 lbs). In other words, this model is 3.17% heavier than the average Endurance bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the CR1 20 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Scott CR1 20 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
This bike is available in 7 sizes. They vary from 157 cm – 204 cm (5.15 ft – 6.69 ft). In conclusion, it won’t take much to find one that’s right for you.
