Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork SunTour NCX -
Groupset XT, Deore -
Suspension Hardtail -
Motor Bosch 250W 63Nm mid-drive -
Battery Bosch Performance 250w System w/ 400wh battery / Intuvia display -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-SUB 6061 Alloy
Suspension Fork
Suntour NCX DLO, w/ Lockout
Drivetrain
Rear Derailleur
Shimano XT RD-T780 SGS
Shift Levers
Shimano Deore SL-T610
Cassette
Shimano CS-HG50-10 11-36 T
Crank
FSA Metropolis 18 T
Chain
KMC X10
Pedals
Xerama SP 823
Wheels
Front Hub
Formula CL51
Rear Hub
Shimano FH-M615 CL
Rims
Mach 1-640
Spokes
Sapim double butted
Tires
Continental E Contact 700x42c
Brakes
Brakes
Shimano BR-M447
Brake Levers
Shimano BL-M506 Disc
Cockpit
Stem
Syncros UC3.0 31.8mm
Handlebar
Syncros UC3.0 620mm, 15° bend
Headset
VP semi integrated
Seat
Saddle
Syncros Urban Commuter 2.5
Seatpost
Syncros UC3.0, 31.6mm
Motor & Battery
Motor
Bosch Performance 250w System w/ 400wh battery / Intuvia display
Battery
Bosch Performance 250w System w/ 400wh battery / Intuvia display
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.7 mm | 1.72 mm | 1.76 mm |
| Front Center | 604 mm | 603 mm | 613 mm | 616 mm |
| Rake | 28 mm | 28 mm | 28 mm | 28 mm |
| Trail | 91 mm | 87 mm | 84 mm | 81 mm |
| Stack | 616 mm | 637 mm | 658.1 mm | 679.2 mm |
| Reach | 377.4 mm | 374.8 mm | 383.2 mm | 386 mm |
| Top Tube Length | 566 mm | 576 mm | 591 mm | 607 mm |
| Seat Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 135 mm | 155 mm | 175 mm | 195 mm |
| Chainstay Length | 490 mm | 490 mm | 490 mm | 490 mm |
| Wheelbase | 1088 mm | 1087 mm | 1096 mm | 1100 mm |
| Bottom Bracket Drop | 56 mm | 56 mm | 56 mm | 56 mm |
| Standover Height | 782 mm | 809 mm | 834 mm | 866 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
E-Sub Sport is part of the Scott E E Sub model. Scott released 3 e-bikes variations of this model so far. You can easily view all of the Scott E E Sub e-bikes models from 2017, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fitness e-bikes average price
Our math shows that the average cost of a dependable Fitness e-bike is 2351$. However, you could also get a good Fitness e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Fitness e-bikes average weight
Fitness e-bikes have an average weight of 22.85 kg (50.38 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
slightly heavier than average, E-Sub Sport has a weight of 23 kg (50.71 lbs). In short, the average Fitness e-bike weight is 0.66% lower than this one.
Overview of components
Fork
The E-Sub Sport comes factory-installed with the SunTour NCX fork. This has a travel range of mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the E-Sub Sport e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Scott E-Sub Sport has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Scott E-Sub Sport e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
