Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FOIL Disc HMF / F01 AERO Carbon tech. Road Race geometry Replaceable Derailleur Hanger
Suspension Fork
FOIL Disc HMX 1" Carbon steerer Integrated Carbon Dropout
Drivetrain
Rear Derailleur
SRAM FORCE eTap AXS 24 Speed Electronic Shift System
Front Derailleur
SRAM FORCE eTap AXS Electronic Shift System
Shift Levers
SRAM FORCE eTap AXS HRD Shift-Brake System
Cassette
SRAM FORCE XG1270 10-33
Crank
SRAM FORCE Crankset 48/35 T
Bottom Bracket
SRAM DUB PF ROAD 86.5
Chain
SRAM FORCE
Wheels
Rims
Syncros Capital 1.0 50 Disc 24 Front / 24 Rear Syncros RWS
Tires
Schwalbe ONE Race-Guard Fold 700x28C
Brakes
Brakes
SRAM FORCE eTap AXS HRD Shift-Brake System Flatmount
Disk Rotors
SRAM Centerline XR rotor 160/F and 160/R
Cockpit
Handlebar
Syncros Creston iC SL Carbon combo
Headset
Syncros Integrated
Seat
Saddle
Syncros Belcarra V-Concept 2.0
Seatpost
Syncros Duncan 1.0 Aero
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.35 mm | 1.38 mm | 1.42 mm | 1.45 mm | 1.48 mm | 1.52 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Front Center | 571 mm | 577 mm | 579 mm | 586 mm | 593 mm | 602 mm | 611 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 77 mm | 73 mm | 67 mm | 64 mm | 61 mm | 59 mm | 59 mm |
| Stack | 495.6 mm | 502 mm | 519.7 mm | 540.5 mm | 561.3 mm | 581.5 mm | 600.7 mm |
| Reach | 363.6 mm | 371.8 mm | 377 mm | 381.9 mm | 387.5 mm | 393 mm | 396.4 mm |
| Top Tube Length | 503 mm | 513 mm | 528 mm | 543 mm | 558 mm | 573 mm | 588 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.6 ° | 73.3 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 410 mm | 430 mm | 460 mm | 480 mm | 500 mm | 520 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73.3 ° | 73.3 ° |
| Head Tube Length | 110 mm | 115 mm | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 403 mm | 403 mm | 403 mm | 403 mm | 403 mm | 403 mm | 403 mm |
| Wheelbase | 965 mm | 971 mm | 973 mm | 980 mm | 987 mm | 995 mm | 1005 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 708 mm | 722 mm | 746 mm | 766 mm | 791 mm | 805 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
About this model
Foil 10 is part of the Scott Foil model. 37 bikes variations carry this model name so far. Take a sneak peek at all Scott Foil bikes models from 2021, by clicking here.
Model range prices
The most economical model, the Scott Foil 30 2021 has a starting price of 3999$. Scott Foil Pro 2021 on the other hand is the most expensive at 8999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Aero bikes
Our math shows that the average cost of a dependable Aero bike is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5999$. Comparing this to the average Aero bike price, we see that the price is 42.46% more expensive.
Aero bikes average weight
If we make a quick analysis of the average weight of an Aero bike, we get 7.34 kg (16.18 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 8 kg (17.64 lbs), the Foil 10 model is a bit heavier than average. In conclusion, the average Aero bike weighs 8.99% less than Foil 10.
Overview of components
Fork material
Foil 10 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Foil 10 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Foil 10 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 157 cm – 204 cm (5.15 ft – 6.69 ft). In short, it won’t be difficult to find the right one for you.
