Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
157cm - 167cm
XS
165cm - 173cm
SM
171cm - 179cm
MD
177cm - 185cm
LG
183cm - 191cm
XL
188cm - 197cm
XXL
194cm - 204cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FOIL DISC HMX / IMP, F01 AERO Carbon tech. Road Race geometry Replaceable Dropout STD Seattube / INT BB
Suspension Fork
FOIL DISC HMX 1 1/4"-1 1/2" Carbon steerer Integrated Carbon Dropout
Drivetrain
Rear Derailleur
Shimano Dura-Ace RD-R9100 22 Speed
Front Derailleur
Shimano Dura-Ace FD-R9100
Shift Levers
Shimano Dura-Ace ST-R9120 Dual control 22 Speed
Cassette
Shimano Dura-Ace CS-R9100 11-30
Crank
Shimano Dura-Ace FC-R9100 Hollowtech II 53x39 T
Bottom Bracket
Shimano SM-BB92-41B
Chain
Shimano Dura-Ace CN-HG901-11
Wheels
Rims
Syncros Meritt 1.0 50 Disc 24 Front / 24 Rear Syncros Plug-in RWS
Tires
Schwalbe ONE V-Guard Fold 700x28C
Brakes
Brakes
Shimano BR-R9170 Hyd Disc 160/F and 160/Rmm SM-RT900 CL Rotor
Cockpit
Handlebar
Syncros Carbon FOIL Combo
Headset
Syncros Integrated
Seat
Saddle
Syncros Belcarra 1.0
Seatpost
Syncros FOIL aero Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.34 mm | 1.37 mm | 1.41 mm | 1.44 mm | 1.47 mm | 1.5 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Front Center | 571 mm | 577 mm | 579 mm | 586 mm | 593 mm | 602 mm | 611 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 77 mm | 73 mm | 67 mm | 64 mm | 61 mm | 59 mm | 59 mm |
| Stack | 504.6 mm | 511 mm | 528.7 mm | 549.5 mm | 570.3 mm | 590.5 mm | 609.7 mm |
| Reach | 372.6 mm | 380.8 mm | 386 mm | 390.9 mm | 396.5 mm | 402 mm | 405.4 mm |
| Top Tube Length | 512 mm | 522 mm | 537 mm | 552 mm | 567 mm | 582 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.6 ° | 73.3 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73.3 ° | 73.3 ° |
| Head Tube Length | 110 mm | 115 mm | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 974 mm | 980 mm | 982 mm | 989 mm | 996 mm | 1004 mm | 1014 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 717 mm | 731 mm | 755 mm | 775 mm | 800 mm | 814 mm | 839 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | 171 cm | 177 cm | 183 cm | 188 cm | 194 cm |
| Rider Max Height | 167 cm | 173 cm | 179 cm | 185 cm | 191 cm | 197 cm | 204 cm |
About this model
Foil RC disc belongs to the Scott Foil model. There are 37 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even though the average price of an Aero bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Aero bikes average weight
If we make a quick analysis of the average weight of an Aero bike, we get 7.34 kg (16.18 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
slightly heavier than average, Foil RC disc has a weight of 7.42 kg (16.36 lbs). To sum up, it’s 1.09% heavier than the average weight of Aero bikes.
Foil RC disc components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Scott Foil RC disc 2019, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 7 sizes available for this model. Rider height can be anywhere between 157 cm – 204 cm (5.15 ft – 6.69 ft). In conclusion, finding one for you shouldn’t be a problem.
